IP-1015WS(NETWORK WALL SPEAKER)
8
1 2 3 45
76 8
Part Names and Function
1. STATUS LED
In normal operation, the green LED flashes every 0.5 seconds.
2. Contact closure I/O terminal
CONTACT IN: Input for contact closure (Dry contact)
CONTACT OUT: Output for contact closure
(N.O : Normally Open, Dry contact)
GND SIG
