Inter-m P-2000 Service Manual

D118 D117 2058300996 DIODE MUR1520 MOTOROLA MUR1520
D108 D110 2058512140 DIODE ZENER 6.2V 1W(1N4735A) 1N4735 6.2V
D113-114 2058501076 DIODE ZENER UZ-7.5BM 7.5V
D115-116 2058514218 DIODE ZENER 1N 5955,(PANJIT) 1N5955A
D127-128 2058510150 DIODE ZENER UZP-15B(13.9,15.9) UZP15BM
D124-125 ( For P- 2000 ) 2058100978 DIODE BRIDGE GL3504 PANJIT GL3504
D124-126 ( For P- 3200 ) 2058100978 DIODE BRIDGE GL3504 PANJIT GL3504
D123 2058100985 DIODE BRIDGE W04G LITEON PB104M
D109 D111 D130-131 2058304100 DIODE 1N4148 1N4148
D120 D119 2058300996 DIODE MUR1520 MOTOROLA MUR1520
D122 D121 2058100105 DIODE LT1N5402 F 1N5402
D112 D132 2058100996 DIODE RECTIFIER LT1N4006(T/R) 1N4006
IC102 ( For P- 2000 ) 2178304091 IC HYBRID SWITCHING A HIC
IC102-103 ( For P- 3200 ) 2178304091 IC HYBRID SWITCHING A HIC
IC101 2178304089 IC HYBRID CONTROL (PSR-2800) HIC
IC104 ( For P- 2000 ) 2178304090 IC HYBRID SWITCHING B HIC
IC104-105 ( For P- 3200 ) 2178304090 IC HYBRID SWITCHING B HIC
IC110 2168640988 IC 7815 SAMSUNG 7815
IC111 2168640987 IC 7915 SAMSUNG 7915
IC107-109 2168220982 IC NE 5532(SIGNETICS) 5532
IC106 2118031107 IC KA2284 S.S KA2284
IC112 2408000101 PHOTO COUPER NTL5C4 (VACTAC) 5224
T3-8 4465998210 TERMINAL(250)PCB TAB 250TAB
T1-2 (For P-3200 ) 4465998211 TERMINAL(251)PCB TAB 251TAB
RA101-102 RA105 3099103273 RES ARRAY 8POL 10K*4 10K
RA104 RA103 RA106 3099102273 RES ARRAY 8POL 1K*4 1K
R101 R108 3009152973 RES CF 1.5K 1/5W J N 1.5K
R103 3009105973 RES CF 1M 1/5W J N 1M
R104 R102 3009103973 RES CF 10K 1/5W J N 10K
R106 3009392973 RES CF 3.9K 1/5W J N 3.9K
R107 3009681973 RES CF 680 1/5W J N 680
R105 R109 3009101973 RES CF 100 1/5W J N 100
R110 R112 R140-141 3003100953 RES CF 1K 1/5W F N 1K 1%
R114 3009334973 RES CF 330K 1/5W J N 330K
R115 3002610953 RES CF 61K 1/5W F N 61K 1%
R116 3009273973 RES CF 27K 1/5W J N 27K
R121 3009682973 RES CF 6.8K 1/5W J N 6.8K
R122 3004405953 RES CF 405 1/5W F N 405 1%
R124 3009753973 RES CF 75K 1/5W J N 75K
R127 3004580953 RES CF 580 1/5W F N 580 1%
R136 3009202973 RES CF 2K 1/5W J N 2K
R137 3009153973 RES CF 15K 1/5W J N 15K
R139 R143 3004332953 RES CF 332 1/5W F N 332 1%
R113 3009471973 RES CF 470 1/5W J N 470
