Inter-m P-2000 Service Manual

R111 3009472973 RES CF 4.7K 1/5W J N 4.7K
R1000 3009470973 RES CF 47 1/5W J N 47
R5 SERVICE
R117-118 3039103572-F RES MO 10K 2W J N 10K 2W
R119 ( For P- 2000 ) 3039822572-F RES MO 8.2K 2W J N 8.2W 2W
R119 ( For P- 3200 ) 3039100572-F RES MO 10 2W J N 10 2W
R125 3039470572-F RES MO 47 2W J N 47 2W
R126 3039473574 RES MO 47K 2W 47K 2W
R128-129 R132-133 3039220572-F RES MO 22 2W J N 22 2W
R146 R153 R168-169
R172-173 (For P-3200)
R132-133 R146 R153 3039220572-F RES MO 22 2W J N 22 2W
R168-169 (For P-2000)
R144-145 R176 3039479572-F RES MO 4.7 2W J N 4.7 2W
R147-152 R154-159 3059228673 RES CE 0.22 3W J RQA T.H 0.22 3W
R167 R134 3039279572-F RES MO 2.7 2W 2.7 2W
R131 R170 (For P-3200) 3039279572-F RES MO 2.7 2W 2.7 2W
R163-164 R160-162 3039100674 RES MO 10 3W 10 3W
R165-166 ( For P-2000 ) 3059302673 RES CE 3K 3W JN 3K 3W
R165 R166 R171 (For P-3200) 3039302574 RES MO 3K 2W 3K 2W
R135 (For P-2000) 3059223673 RES CE 22K 3W JN 22K 3W
R130 R135 (For P-3200) 3039223574 RES MO 22K 2W 22K 2W
R142 R138 3039754574 RES MO 750K 2W 750K 2W
R123 ( For P- 2000 ) 3002215353 RES CF 21.5K 1/2W FN 21.5K 1/2W
R123 ( For P- 3200 ) 3002303334 RES CF 30K 1/2W FN 1% 30K 1/2W
R174 2438200040 POSISTOR P42T7D100B04 PTC-60C
PSR-2800
TH102 2438200060 THERMISTOR NTC5D-400KPC 50ohm 25 C
S7 SAFTY SAFTY SAFTY
PSW101-102 2423000999 SW POLY 50VX110 JX3K-T JX3K-T
Q121-124( For P- 2000 ) 2048209999 FET IRFZ44 (SEC) IRFZ44
Q119-126( For P- 3200 ) 2048209999 FET IRFZ44 (SEC) IRFZ44
Q101 2028348100-T TR NPN MPSW01A MOTOROLA MPSW01
Q102-103 2008448098-T TR NPN 2N4410 MOTOROLA 2N4410
Q105 2028407995 TR NPN E15032(MOTOROLA) E15032
Q113-118 2028407122 TR NPN 2SC3281 .0/WACC 2SC3281
Q104 2008448098-T TR NPN 2N4410 MOTOROLA 2N4410
Q106 2028107995 TR PNP E15033 (MOTOROLA) E15033
Q107-112 2028107118 TR PNP 2SA1302(0)2SA1215 2SA1302
SVR101 3248310120 RES SEMI CS 100B 10/5 100B
SVR102-103 3248310320 RES SEMI CS 10KB 10/5 10KB
CN102 4428556212 CONNECTOR WAFER AMP 12P(6.5MM) CON12P
AN104 4355813110 CONNECTOR ASS'Y 13P(LED METER) CON13P
CN103 NOT USED
