MIXING AMPLIFIER
10
PA-60/120/240
※Warning : For high impedance systems, connect with matching transformer as the following Figure.
B
e certain that the total impedance is not less than the rated impedance.
※Warning : Please do not use 8/4Ω output terminal and SP1~SP5 (100V or 70V) output terminals at the same time.
*NOTE : Please note that SP1~SP5 output voltage (100V or 70V) is different as the region.
