MIXING AMPLIFIER
14
PA-60/120/240
Specifications
Specifications
PA-60 PA-120 PA-240
●100V/70V High-Z Output
Rated Output Power (@1kHz, THD 1%) 60W 120W 240W
Frequency Response (@ 1W, Rated Load, ±3dB) 80Hz ~ 17kHz
THD (@ Rated Power, 1kHz) Less than 1%
S/N (Line input) more than 78dB
TONE CONTROL (100Hz, 10kHz, ±3dB) ±10dB
Input Sensitivity / Impedance
INPUT 1~5
MIC -50dBu / 2kΩ (Balance)
LINE -10dBu / 2kΩ (Balance)
INPUT 6 -10dBu / 10kΩ (Balance)
TEL IN 0dBu / 10kΩ (Balance)
EXT IN 0dBu / 20kΩ (Unbalance)
MIX OUT / Impedance 0dBu / 10kΩ (Unbalance)
Speaker Output Level/Impedance
100V region 100V / 167Ω 100V / 84Ω 100V / 42Ω
70V region 70V / 82Ω 70V / 41Ω 70V / 21Ω
●8/4Ω Output
Rated Output Power
(@1kHz, THD 1%)
8Ω 40W 120W 180W
4Ω 60W 160W 240W
Frequency Response (@ 1W, 8Ω, ±3dB) 80Hz – 20kHz
●General Specifications
Operation Temperature -10℃ ~ +40℃
Power Source
AC 120V/60Hz or AC 230V/50Hz or AC 240V/50Hz
(Supplied AC mains transformer depends on contrary
requirements)
Power Consumption (1/8W output) 40W 60W 90W
Weight (SET) 6.2kg / 13.7Ib 7.4kg / 16.3Ib 9.8kg / 21.6Ib
Dimensions (SET)
420(W) x 88(H) x 319(D)mm
16.5(W)x3.5(H)x12.6(D)in
* Design and specification are subject to be changed for the improvement of product quality without pre notice.
* Plese note that High-Z SP1~SP5 output voltage (100V or 70V) is different as the region.
