MIXING AMPLIFIER
5
PA-60/120/240
9
. POWER INDICATOR
This LED Lights when the unit is powered on.
10. SPEAKER ZONE SELECTION SWITCH
Use the speaker zone selection switches to route the program audio from the amplifier output to speaker
zone 1 through zone 5. The 'ALL' switch turns on all zones. The Indicators light when speaker zone selection
switches are on.
* When power goes off and back on, speaker zone selection switches are set as a setting of 'SPEAKER PRESET'
switch of rear panel.
* When 'ALL' switch is on, signals are out in all zones regardless of the status of SP1~SP5 switch.
* When 'ALL' switch is on, LEDs of the turned-off speaker zones light half, Half-lit speaker zones will be turned
off when 'ALL' switch is off.
Ex)
11. OUTPUT LEVEL DISPLAY
Displays the output level meter, each bar is marked in intervals of 3 to 4dB.
STEP ALL SP1 SP2 SP3 SP4 SP5 Output
1 OFF ON OFF ON OFF OFF 1,3 Zones
2 ON ON Half-lit ON Half-lit Half-lit All Zones
3 OFF ON OFF ON OFF OFF 1,3 Zones
