PUBLIC ADDRESS POWER AMPLIFIER
11
PA-9312/9324A/9336/9348
Specifications
Specifications
PA-9312 PA-9324A PA-9336 PA-9348
Rated Output Power (THD 5%, 1kHz)
120W 240W 360W 480W
Frequency Response (+1/-3dB) 70Hz-18kHz
T.H.D Less than 1% Less than 5%
High Pass Filter (400Hz) -3dB
Gain Control -12dB
S/N Better than 95dB Better than 90dB
Input Sensitivity/Impedance 1V/10kΩ Balanced
Output Voltage/Impedance 4Ω/22V 4Ω/31V 4Ω/38V 4Ω/43.8V
5.2Ω/25V 2.6Ω/25V 8Ω/54V 8Ω/62V
41Ω/70V 21Ω/70V 13.6Ω/70V 10.2Ω/70V
83Ω/100V 42Ω/100V 27.8Ω/100V 20.8Ω/100V
Operating Temperature -10
°C
~ +40
°
C
Power Source 100–120VAC or 220–240VAC; 50/60Hz, 24VDC
(Supplied AC mains transformer depends on country requirements)
Power Consumption (1/8 power) 130W 380W 380W 600W
Weight (SET) 14kg/30.8lb 19kg/41.9lb 19kg/41.9lb 22kg/48lb
Dimensions (SET) 482(W)×132(H)×280(D)mm/19(W)x5.2(H)x11(D)in
* Specifications and design subject to change without notice.
