CON1 4428598307 CONNECTOR WAFER LW-0640-7P 7P
P1-2 P5-6 4465998210 TERMINAL(250)PCB TAB 250TERMINAL
TP1/2 4678699411 CNT PLUG 1P 1P
Q2-3 S20160505001 TR NPN KTC4375-Y-RTF SOT-89 KTC732
C124 C123 3539332331-A CAP CE YR 3300PF 16V M AXIAL 3300P
C127 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50
R97
DC FUSE (PA-9312) 4458999310 FUSE CARRIER FEK-0031.1661 SUT 220V 60Hz
240V 50Hz
120V 60Hz
4458999410 FUSE CARRIER FEU-0031.1663 SUT 230~240V 50Hz
230V 50Hz
DC FUSE (PA-9324) 4458999310 FUSE CARRIER FEK-0031.1661 SUT 220V 60Hz
P11-12 4465998210 TERMINAL(250)PCB TAB 250TERMINAL
IC01A 2118010332 IC NJM 5532DD JRC NJM 5532DD
R6-7 R11 R18 3009103973 RES CF 10K 1/5W J N 10K 1%
R5 3009104973 RES CF 100K 1/5W J N 100K 1%
R121 3009152973 RES CF 1.5K 1/5W J N 1.5K 1%
R13-14 3009473973 RES CF 47K 1/5W J N 47K 1%
R1-2 R12 R15 3009562973 RES CF 5.6K 1/5W J N 5.6K 1%
R3-4 3009822973 RES CF 8.2K 1/5W J N 8.2K 1%
VR1 3238081410 VR RV09A-20-25K-B53(ALPHA) 5KB
C3-4 C11 C13-14 C17 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50
C6 3409247871-T CAP AF RSG 0.47UF 50V 5 P 0.47/50
C12 C15 3509101130-T CAP CE SL 100PF 50V J 100P
C1-2 3509102530-T CAP CE B 0.001UF 50V J 0.001/50
C5 C16 3509221130-T CAP CE SL 220PF 50V J 220P
C120 3609103120-T CAP MA 0.01UF 100V 0.01/100(M)
C121-122 3609683120-T CAP MA 0.068UF 100V J 0.068/100(M)
CON101 4353989510 CONNECTOR ASS'Y 7P 7P
JK2 4408194610 XLR JACK (M) (E403A0090N) XLR JACK
CON2 4428595002 LW5267/LWB0640/2.5MM-02P CN 2P
JK1 4438193710 XLR JACK(F) 3P(E303A0070N) XLR 3P(F)
P15-16 4465998210 TERMINAL(250)PCB TAB 250TERMINAL
SW1-2 4618001110 SW SV10020-0202-9T-SN
SV10020-0202
P23 4678699411 CNT PLUG 1P CNT1P
Q102-105 2008606104-T TR NPN KTC3198-Y-AT TO-92 KTC 3198Y
Q101 2008606108-T KTC3200-BL-AT C2240
D101-103 2058502120 DIODE ZENER UZ-12BM(1N5242B) UZ 12BM
IC04-A1 2118010590 IC NJM4558D JRC NJM 4558D
JACK B'D (4005196010)
LED1 B'D (4005196020)
