Inter-m PA-9324 Service Manual

IC03A 2118010590 IC NJM4558D JRC NJM 4558D
D104-105 2300050105 LED LTL-307E-041A LITEON LTL-307E-041A
D106-107 2300052105 LED LTL-307G-041A LITEON LTL-307G-041A
R109 3009101973 RES CF 100 1/5W J N 100
R122 3009102973 RES CF 1K 1/5W J N 1K
R113 R115 R117-120 3009202973 RES CF 2K 1/5W J N 2K
R105 3009222973 RES CF 2.2K 1/5W J N 2.2K
R108 3009272973 RES CF 2.7K 1/5W J N 2.7K
R101 3009333973 RES CF 33K 1/5W J N 33K
R103 3009334973 RES CF 330K 1/5W J N 330K
R107 3009472973 RES CF 4.7K 1/5W J N 4.7K
R123 3009561973 RES CF 560 1/5W J N 560
R110-112 3009682973 RES CF 6.8K 1/5W J N 6.8K
R102 R106 3009822973 RES CF 8.2K 1/5W J N 8.2K
C101 C103 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50
C104-106 3409247971-T CAP AF RSG 4.7UF 50V 5 P 4.7/50
CON103 4428598704 CONNECTOR WAFER LA-0640-4P LA-04P
C107 3509100130-T CAP CE SL 10PF 50V D 10P
CON5 4428596605 LOCK WAFER LW-1143-05P 5P
J1 J2 J3 J4-1-2 JUMPER JUMPER JUMPER
TER 4465997704 SCREW TERMINAL 4P 4P
P24 4678699411 CNT PLUG 1P CNT1P
R124 3039821572 RES MO 820 2W JN 820 2W
C125 COO1 C126 3509102556 CAP CE 0.001UF 500V 0.001/500
D701 2300050101 LED LTL-307E-012A LTL-307E-012A
CON102 4353986914 CON ASS'Y 2P LA 2P
C100 3549472407 CAP DE2E3KH472MA4B 0.0047/400
P19-21 4465998210 TERMINAL(250)PCB TAB 250TERMINAL
P22 4465998210 TERMINAL(250)PCB TAB 250TERMINAL
S1 4648099010
POWER SWITCH ESB-99831V MASTUS
220V/110V
ASS'Y
POWER TRANS (PA-9312) 2828079500 TRANSFORMER POWER PA-9312 220V 60Hz
240V50Hz
2828079501 POWER TRANS(EUROPE) PA-9312 230~240V 50Hz
230V 50Hz
2828079510 POWER TRANS (UL) PA-9312 120V 60Hz
POWER TRANS (PA-9324) 2828079400 TRANSFORMER POWER PA-9324 220V 60Hz
2828079401 POWER TRANS(EUROPE) PA-9324 230~240V 50Hz
230V 50Hz
SW B'D (4005196050)
TERMINAL B'D (4005196040)
LED2 B'D (4005196030)
4 / 5
