Inter-m PD-6359 User Manual

POWER DISTRIBUTOR
9
PD-6359
11. DC POWER OUTPUT TERMINAL (FOR AMP)
It is the terminal which outputs the emergency DC power (Battery) in case of AC black out. Connect it to AMP
D
C INPUT.
12. BATTERY POWER INPUT TERMINAL
It is the terminal which connects the emergency power to use the system in case of black out, and It normally
connects to the battery. Caution to polarities when it connects.
13. DC POWER OUTPUT TERMINAL (FOR RACK)
It is the terminal supplying DC power to the rack system as rated 24V power output. It can be controlled with
front power switch ON/OFF or remotely.

Inter-m PD-6359 Specifications

General

Brand	Inter-m
Model	PD-6359
Category	Power distribution unit
Language	English
