Inter-m POP-120 - Page 2

Ref No. Part No. Description Value Qty Remark
C1-2 C5-6 C9-10 C13 3509102530-T CAP CE B 0.001UF 50V J 0.001/50 7
C15 3509223530-T CAP CE F 0.022UF 50V Z 0.022/50 1
C55-58 3509104530-T CAP CE F 0.1UF 50V Z 0.1/50 4
C3 C7 C11 3509150130-T CAP CE SL 15PF 50V J 15P 3
C8 C12 3509330130-T CAP CE SL 33PF 50V J 33P 2
C16 3509470130-T CAP CE SL 47PF 50V J 47P 1
C14 3509509030-T CAP CE SL 5PF 50V J 5P 1
C4 3509680130-T CAP CE SL 68PF 50V J 68P 1
C27 C36-37 3409210971-T CAP AF RSG 1UF 50V 5 P 1/50 3
C49-54 3409210171-T CAP AF RSG 100UF 50V 8 P 100/50 6
C59-60 3408210271 CAP RSA 1000UF 50V SNAP 16 P 1000/50 2
C35 3409222071-T CAP AF RSG 22UF 50V 5 P 22/50 1
C47-48 3409222171-T CAP AF RSG 220UF 50V SG 10 P 220/50 2
C24 C30-32 3409233071-T CAP AF RSG 33UF 50V 6 P 33/50 4
C22-23 C25-26 3409247971-T CAP AF RSG 4.7UF 50V 5 P 4.7/50 8
C28-29 C33-34
C38-44 3409247041-T CAP AF RSG 47UF 25V 5 P 47/25 7
C20 3609103120-T CAP MA 0.01UF 100V 0.01/100(M) 1
C17-18 3609153120-T CAP MA 0.015UF 100V J 0.015/100(M) 2
C19 C21 C45-46 3609104122-T CAP MA 0.1UF 100V J SMALL 0.1/100(M) 4
CON4 CON6-8 4428595002 LW5267/LWB0640/2.5MM-02P LW-5267-2P 3
CON2
4428598303
CONNECTOR WAFER LW-0640-3P LW-0640-3P 1
CON3
4428596603
LOCK WAFER LW-1143-03P LW-1143-3P 1
CON29 4355887114 CON ASS'Y 3P ASS'Y 3P 1
CON5
4428598308
CONNECTOR WAFER LW-0640-8P
LW-0640-8P
1
CON1
4428598309
CONNECTOR WAFER LW-0640-9P
LW-0640-9P
1
D5-8 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006 4
D1-3 D30-41 2058304100 DIODE IN4148M 1N 4148 15
D4 2058502056 DIODE ZENER UZ-5.6BM(1N5232B) UZ 5.6BM 1
FB1-6 2648609900 FERITE BEAD H5B FERRITE BEAD 6
FR-4 3089100275 RES NFR 10 1/4W J R PHILKO FR 10 1
FR-1 FR-3 3079479275 RES ERD-2FCVG 4R7T 1/4W R FR 4.7 2
FR-2 3079470275 RES ERD-2FCVG 470T 1/4W R FR 47 1
IC4 2128611000 IC KA7818 COMMON 7818 1
8099130121 HEX MSPM 3*12Y
IC5 2128611100 IC KA7918 COMMON 7918 1
7505299320 HEAT SINK(45MM) REG TR
8099130121 HEX MSPM 3*12Y
IC6-7 2128610500 IC 7812 COMMON 7812 2
7505299320
8099130121
IC1 2128740208
IC BXA 4240 일진ㅤ전자
BXA4240 1
IC2-3 2118010432 IC NJM2068DD JRC NJM 2068DD 2
JK1-3 4438098910 JACK PHONE(DAE RYUNG MA-8001) JACK PHONE 3
Q2-5 2008606998-T KTD1302-AT 2SD 1302R 4
Q1 2008606105-T TR NPN KTA1266-Y-AT TO-92 2SA 1266GR 1
R7 R14 R21 R24 R38 3009101973 RES CF 100 1/5W J N 100 5
R6 R13 R20 R34-35 3009104973 RES CF 100K 1/5W J N 100K 5
R1-2 R8-9 R15-16 3009103973 RES CF 10K 1/5W J N 10K 10
R22-23 R30 R47
R31 R40 3009123973 RES CF 12K 1/5W J N 12K 2
R12 R19 3009154973 RES CF 150K 1/5W J N 150K 2
R33 3009153973 RES CF 15K 1/5W J N 15K 1
R10-11 R17-18 R27 3009102973 RES CF 1K 1/5W J N 1K 6
R36
R28 3009105973 RES CF 1M 1/5W J N 1M 1
R42 3009225973 RES CF 2.2M 1/5W J N 2.2M 1
R52 3039200575-T RES MO 20 2W J RADIAL 20 2W 1
ELECTRICAL PARTS LIST ( POP - 30/60/120 )
MAIN B'D (4005412801)
