ELECTRICAL PARTS LIST
Ref No. Part No. Description Value
MAIN B'D (4005106000)
Q101-115 Q201 2008606104-T TR NPN KTC3198-Y-AT TO-92 KTC 3198Y
Q203
Q403 2008606105-T TR NPN KTA1266-Y-AT TO-92 KTA1266Y
Q202 Q401-402 2008606998-T KTD1302-AT 2SD 1302R
D501-4 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N4006*4
D401-402 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006
D505-507
D403 2058304107 DIODE SCH0TTKY SB-150 (SR105) SB-150
IC115 2118010332 IC NJM 5532DD JRC NJM 5532DD
IC101 IC103 2118010432 IC NJM2068DD JRC NJM 2068DD
IC105 IC107
IC111
IC102 IC104 2118010590 IC NJM4558D JRC NJM 4558D
IC106
IC108-110
IC112-114
IC401-402 2128610900 IC KA7815 COMMON 7815
FB101-114 2648609900 FERITE BEAD H5B H5B
R344-345 R606 3009100973 RES CF 56K 1/5W J N 10
R195 R211 R221 3009102973 RES CF 1K 1/5W J N 1K
R232 R243 R299
R301 R310 R402
R263-273 R281 3009103973 RES CF 10K 1/5W J N 10K
R317 R337-339
VR101
R196-197 R209 3009104973 RES CF 100K 1/5W J N 100K
R254-255 R262
R297 R302-303
R306-307
R311-312
R326-327 R602
R140 R155 R170 3009105973 RES CF 1M 1/5W J N 1M
R185 R202 R215
R220 R225 R231
R236 R242 R247
R324 R601
