6
PT-9107SD
STEREO TUNER
7. CHANNEL INDICATOR
The CHANNEL INDICATOR displays the selected channel’s MEMORY number as well as the MODE
(Preset or tune).
8. BROADCAST BAND INDICATOR
This indicates whether AM or FM has been selected.
9. MEMORY DISPLAY
The word MEMORY is displayed to confirm that the MEMORY function is ready to operate.
10. TUNING INDICATOR
The word TUNE is displayed to confirm that a radio station is broadcasting on the selected frequency.
11. MONO/ST BUTTON
This button changes the Stereo output (located on the rear panel) to a Mono output.
12. AM FM BUTTONS
Depressing these buttons selects between the AM and FM bands.
13. UP DOWN BUTTONS
Depressing either of these buttons will tune UP or DOWN in frequency. Depressing and holding either
button for 2 seconds will cause the Tuner to move UP or DOWN to the next broadcast signal.
