Inter-m SC-624 User Manual

9
ELECTRICAL PARTS LIST
Ref. Part No. Description Value
R243 119619 “RES,TF,470,1/16W,5%,1608” 470
R244 119619 “RES,TF,470,1/16W,5%,1608” 470
R245 119619 “RES,TF,470,1/16W,5%,1608” 470
R246 119619 “RES,TF,470,1/16W,5%,1608” 470
R247 119619 “RES,TF,470,1/16W,5%,1608” 470
R248 119619 “RES,TF,470,1/16W,5%,1608” 470
R249 119619 “RES,TF,470,1/16W,5%,1608” 470
R250 119619 “RES,TF,470,1/16W,5%,1608” 470
R251 119619 “RES,TF,470,1/16W,5%,1608” 470
R252 119619 “RES,TF,470,1/16W,5%,1608” 470
R253 119619 “RES,TF,470,1/16W,5%,1608” 470
R254 119619 “RES,TF,470,1/16W,5%,1608” 470
R255 119619 “RES,TF,470,1/16W,5%,1608” 470
R256 119619 “RES,TF,470,1/16W,5%,1608” 470
R257 119619 “RES,TF,470,1/16W,5%,1608” 470
R258 119619 “RES,TF,470,1/16W,5%,1608” 470
R259 119619 “RES,TF,470,1/16W,5%,1608” 470
R260 119619 “RES,TF,470,1/16W,5%,1608” 470
R261 119619 “RES,TF,470,1/16W,5%,1608” 470
R262 119619 “RES,TF,470,1/16W,5%,1608” 470
R263 119619 “RES,TF,470,1/16W,5%,1608” 470
R264 119619 “RES,TF,470,1/16W,5%,1608” 470
R265 119619 “RES,TF,470,1/16W,5%,1608” 470
R266 119619 “RES,TF,470,1/16W,5%,1608” 470
R267 119619 “RES,TF,470,1/16W,5%,1608” 470
R268 119619 “RES,TF,470,1/16W,5%,1608” 470
R269 119619 “RES,TF,470,1/16W,5%,1608” 470
R270 119619 “RES,TF,470,1/16W,5%,1608” 470
R271 119619 “RES,TF,470,1/16W,5%,1608” 470
R272 119619 “RES,TF,470,1/16W,5%,1608” 470
U201 119127 “IC,SHIFT REGISTER,74HC595D,SOIC16” 74HC595D
U202 119127 “IC,SHIFT REGISTER,74HC595D,SOIC16” 74HC595D
U203 119127 “IC,SHIFT REGISTER,74HC595D,SOIC16” 74HC595D
U204 119127 “IC,SHIFT REGISTER,74HC595D,SOIC16” 74HC595D
U205 119127 “IC,SHIFT REGISTER,74HC595D,SOIC16” 74HC595D
U206 119127 “IC,SHIFT REGISTER,74HC595D,SOIC16” 74HC595D
U207 119127 “IC,SHIFT REGISTER,74HC595D,SOIC16” 74HC595D
U208 119127 “IC,SHIFT REGISTER,74HC595D,SOIC16” 74HC595D
U209 119127 “IC,SHIFT REGISTER,74HC595D,SOIC16” 74HC595D
U210 119127 “IC,SHIFT REGISTER,74HC595D,SOIC16” 74HC595D
AN201 109094 “CON ASS’Y,FL,3P,5395,5264,250MM” ASS’Y-03P
AN202 107248 “CON ASS’Y,FL,6P,VHR,SDN,100MM” ASS’Y-06P
AN203 107248 “CON ASS’Y,FL,6P,VHR,SDN,100MM” ASS’Y-06P
AN204 107248 “CON ASS’Y,FL,6P,VHR,SDN,100MM” ASS’Y-06P
AN205 107248 “CON ASS’Y,FL,6P,VHR,SDN,100MM” ASS’Y-06P
AN206 107248 “CON ASS’Y,FL,6P,VHR,SDN,100MM” ASS’Y-06P
AN207 107248 “CON ASS’Y,FL,6P,VHR,SDN,100MM” ASS’Y-06P
AN208 107248 “CON ASS’Y,FL,6P,VHR,SDN,100MM” ASS’Y-06P
AN209 107248 “CON ASS’Y,FL,6P,VHR,SDN,100MM” ASS’Y-06P
BK1 113478 BKT.PCB PS-M350 Bracket
BK2 113478 BKT.PCB PS-M350 Bracket
BK3 113478 BKT.PCB PS-M350 Bracket
BK4 113478 BKT.PCB PS-M350 Bracket
BK5 113478 BKT.PCB PS-M350 Bracket
JK1 111451 “JACK,DSUB(M),1U,9P,2/AN,RIVET TYPE” D-SUB09P
INPUT B’D
