Inter-m SC-624 User Manual

10
ELECTRICAL PARTS LIST
Ref. Part No. Description Value
I1/2 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I10/11 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I11/12 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I13/14 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I14/15 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I16/17 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I17/18 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I19/20 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I2/3 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I20/21 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I22/23 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I23/24 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I4/5 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I5/6 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I7/8 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
I8/9 110793 “TERMINAL,BLOCK SCREW,3P,5MM,ST,BL-5045GL” TERMINAL03P
AN102B 109212 “CON ASS’Y,FL,2P,35022,5264,300MM” ASS’Y-02P
LD_PWR 103252 “LED,RND,3.1MM,BLU,CLR,1U,ST2.5” LTL1CHTBK1
R101 119620 “RES,TF,470,1/10W,5%,2012” 470
AN102A 109094 “CON ASS’Y,FL,3P,5395,5264,250MM” ASS’Y-03P
SW_PWR 112010 “SW,PUSH,HOR,DPDT,NS,1U,BKT,L18” SPUN12X1T071
LD201 119235 “LED,SMD,BLU,CLR,1U,1608,TA” BUZZER
LD202 119235 “LED,SMD,BLU,CLR,1U,1608,TA” AUTO CHECKER
R293 119625 “RES,TF,4.7K,1/10W,5%,2012” 4.7K
R294 119625 “RES,TF,4.7K,1/10W,5%,2012” 4.7K
R295 119620 “RES,TF,470,1/10W,5%,2012” 470
R296 119620 “RES,TF,470,1/10W,5%,2012” 470
SW203 112204 S/W TACTIL (LS4.5X8MM) BUZZER
SW204 112204 S/W TACTIL (LS4.5X8MM) AUTO CHECKER
VR4 104988 “VR,ROT,VER,1U,L15,20K,A” 20KA
CN104 111346 “CON WAFER,BOX(M),6P,AN” LA5268-06P
CN103 111346 “CON WAFER,BOX(M),6P,AN” LA5268-06P
LD203 119235 “LED,SMD,BLU,CLR,1U,1608,TA” CONFIRM
LD204 119235 “LED,SMD,BLU,CLR,1U,1608,TA” TEST/START
R291 119625 “RES,TF,4.7K,1/10W,5%,2012” 4.7K
R292 119625 “RES,TF,4.7K,1/10W,5%,2012” 4.7K
R297 119620 “RES,TF,470,1/10W,5%,2012” 470
R298 119620 “RES,TF,470,1/10W,5%,2012” 470
SW201 112204 S/W TACTIL (LS4.5X8MM) CONFIRM
SW202 112204 S/W TACTIL (LS4.5X8MM) TEST/START
AN103 107249 “CON ASS’Y,FL,6P,5264,35022,50MM” ASS’Y-06P
AN104 107249 “CON ASS’Y,FL,6P,5264,35022,50MM” ASS’Y-06P
FUSE 112582 “FUSE,20MM,T,1A,250V,K/U/CS/J” 1A/250V
POWER LED B’D
POWER SW B’D
SW1 B’D
SW2 B’D
ASS’Y
