Inter-m SC-624 User Manual

Ref. Part No. Description Value
Q1 102541 “TR,SG,NPN,150MA,50V,KTC3198BL,TO-92,TA” C3198BL
Q2 102526 “TR,SG,PNP,150MA,50V,KTA1266Y,TO-92,TA” A1266Y
Q3 102526 “TR,SG,PNP,150MA,50V,KTA1266Y,TO-92,TA” A1266Y
Q4 102541 “TR,SG,NPN,150MA,50V,KTC3198BL,TO-92,TA” C3198BL
Q5 102541 “TR,SG,NPN,150MA,50V,KTC3198BL,TO-92,TA” C3198BL
Q6 102541 “TR,SG,NPN,150MA,50V,KTC3198BL,TO-92,TA” C3198BL
Q7 102525 “TR,SG,NPN,150MA,50V,KTC3198Y,TO-92,TA” KTC3198-Y
Q8 102525 “TR,SG,NPN,150MA,50V,KTC3198Y,TO-92,TA” KTC3198-Y
R1 119946 RES MF 2.4K J 2012 2.4K
R10 119362 “RES,TF,1K,1/10W,5%,2012” 1K
R100 119367 “RES,TF,10K,1/10W,5%,2012” 10K
R11 119605 “RES,TF,3.9K,1/10W,5%,2012” 3.9K
R12 119373 “RES,TF,1M,1/10W,5%,2012” 1M
R13 119654 “RES,TF,5.1K,1/10W,5%,2012” 5.1K
R14 119654 “RES,TF,5.1K,1/10W,5%,2012” 5.1K
R15 119367 “RES,TF,10K,1/10W,5%,2012” 10K
R16 119654 “RES,TF,5.1K,1/10W,5%,2012” 5.1K
R17 119576 “RES,TF,3.3K,1/10W,5%,2012” 3.3K
R18 119367 “RES,TF,10K,1/10W,5%,2012” 10K
R19 119367 “RES,TF,10K,1/10W,5%,2012” 10K
R2 119373 “RES,TF,1M,1/10W,5%,2012” 1M
R20 119470 “RES,TF,200,1/10W,5%,2012” 200
R21 119470 “RES,TF,200,1/10W,5%,2012” 200
R22 119470 “RES,TF,200,1/10W,5%,2012” 200
R23 119470 “RES,TF,200,1/10W,5%,2012” 200
R24 119517 “RES,TF,24K,1/10W,5%,2012” 24K
R25 119517 “RES,TF,24K,1/10W,5%,2012” 24K
R26 119517 “RES,TF,24K,1/10W,5%,2012” 24K
R27 119517 “RES,TF,24K,1/10W,5%,2012” 24K
R28 119423 “RES,TF,1.5K,1/10W,5%,2012” 1.5K
R29 119732 RES TF 7.5K J 1/10W 2012 7.5K
R3 119362 “RES,TF,1K,1/10W,5%,2012” 1K
R30 119554 “RES,TF,30K,1/10W,5%,2012” 30K
R31 119701 “RES,TF,680,1/10W,5%,2012” 680
R32 119707 “RES,TF,6.8K,1/10W,5%,2012” 6.8K
R33 119625 “RES,TF,4.7K,1/10W,5%,2012” 4.7K
R34 119654 “RES,TF,5.1K,1/10W,5%,2012” 5.1K
R35 119434 “RES,TF,150K,1/10W,5%,2012” 150K
R36 119476 “RES,TF,20K,1/10W,5%,2012” 20K
R37 119353 “RES,TF,100,1/10W,5%,2012” 100
R38 119367 “RES,TF,10K,1/10W,5%,2012” 10K
R39 119370 “RES,TF,100K,1/10W,5%,2012” 100K
R4 119499 “RES,TF,22K,1/10W,5%,2012” 22K
R40 119617 “RES,TF,47,1/10W,5%,2012” 47
R41 119561 “RES,TF,3M,1/10W,5%,2012” 3M
R42 119362 “RES,TF,1K,1/10W,5%,2012” 1K
R43 119353 “RES,TF,100,1/10W,5%,2012” 100
R44 119370 “RES,TF,100K,1/10W,5%,2012” 100K
R45 119367 “RES,TF,10K,1/10W,5%,2012” 10K
R46 119373 “RES,TF,1M,1/10W,5%,2012” 1M
R47 119367 “RES,TF,10K,1/10W,5%,2012” 10K
R48 119370 “RES,TF,100K,1/10W,5%,2012” 100K
R49 119657 “RES,TF,51K,1/10W,5%,2012” 51K
R5 119404 “RES,TF,120K,1/10W,5%,2012” 120K
R50 119353 “RES,TF,100,1/10W,5%,2012” 100
R51 119353 “RES,TF,100,1/10W,5%,2012” 100
R52 119367 “RES,TF,10K,1/10W,5%,2012” 10K
5
ELECTRICAL PARTS LIST
