Inter-m SC-624 User Manual

6
ELECTRICAL PARTS LIST
Ref. Part No. Description Value
R53 104668 “RES,MF,4.7,2W,5%,RA R,TA” 4.7 2W
R54 104668 “RES,MF,4.7,2W,5%,RA R,TA” 4.7 2W
R55 119654 “RES,TF,5.1K,1/10W,5%,2012” 5.1K
R56 119630 “RES,TF,47K,1/10W,5%,2012” 47K
R57 104606 RES MO 2.2 2W JR 2.2 2W
R58 104668 “RES,MF,4.7,2W,5%,RA R,TA” 4.7 2W
R59 119404 “RES,TF,120K,1/10W,5%,2012” 120K
R6 119686 “RES,TF,620,1/8W,5%,2012” 620
R60 119367 “RES,TF,10K,1/10W,5%,2012” 10K
R61 119630 “RES,TF,47K,1/10W,5%,2012” 47K
R62 119630 “RES,TF,47K,1/10W,5%,2012” 47K
R63 119620 “RES,TF,470,1/10W,5%,2012” 470
R64 119620 “RES,TF,470,1/10W,5%,2012” 470
R65 119367 “RES,TF,10K,1/10W,5%,2012” 10K
R66 119367 “RES,TF,10K,1/10W,5%,2012” 10K
R7 119688 “RES,TF,6.2K,1/10W,5%,2012” 6.2K
R8 119688 “RES,TF,6.2K,1/10W,5%,2012” 6.2K
R9 119367 “RES,TF,10K,1/10W,5%,2012” 10K
RY1 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY10 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY11 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY12 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY13 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY14 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY15 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY16 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY17 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY18 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY19 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY2 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY20 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY21 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY22 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY23 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY24 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY25 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY26 112635 “RELAY,DPST,24V,3A,125V,842” 24V
RY3 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY4 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY5 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY6 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY7 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY8 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
RY9 112713 “RELAY,DPDT,24V,845N-2C-C” 24V
SW_W/N 111972 SW SLIDE SSAF122NB011 SSAF122NB011
T2 103642 “TRANS,MATCH,600OHM,600OHM,CS-197” 2818085600
U1 118779 “IC,MPU,ATMEGA168,TQFP32” ATMEGA168
U10 102816 “IC,OP AMP,NJM4558D,DIP8” 4558D
U11 102816 “IC,OP AMP,NJM4558D,DIP8” 4558D
U12 119127 “IC,SHIFT REGISTER,74HC595D,SOIC16” 74HC595D
U13 103011 “IC,DEMUX,74HC238P,DIP16” 74HC238
U14 103121 “IC,DARLINGTON ARRAYS,ULN2803APG,DIP18” ULN2803
U15 103011 “IC,DEMUX,74HC238P,DIP16” 74HC238
U16 103121 “IC,DARLINGTON ARRAYS,ULN2803APG,DIP18” ULN2803
U17 103121 “IC,DARLINGTON ARRAYS,ULN2803APG,DIP18” ULN2803
U18 103011 “IC,DEMUX,74HC238P,DIP16” 74HC238
U2 103096 “IC,TRANSCEIVER,RS232,SP232ACP-L,DIP14” MAX232
