ELECTRICAL PARTS LIST
Ref. Part No. Description Value
U23 102828 “IC,VOLT REG,18V,7818,TO-220IS” 7818
U3 103122 “IC,INVERTER,TC4069UB,DIP14” TC4069UBP
U4 119081 “IC,POTENTIOMETER,NV TRIMMER,DS1804,118” DS1804
U5 103116 “IC,COUNTER,16P,74HC4060,SOT38-4” 74HC4060U6
102816 “IC,OP AMP,NJM4558D,DIP8” 4558D
U7 102816 “IC,OP AMP,NJM4558D,DIP8” 4558D
U8 102814 “IC,OP AMP,NJM5532DD,DIP8” 5532DD
U9 102816 “IC,OP AMP,NJM4558D,DIP8” 4558D
X1 106131 “X-TAL,8.000MHZ,30PPM,HC-49/S” 8MHz
X2 106111 “X-TAL,480KHZ,°æ2KHZ,CSB_E,7*9*3.5(W*H*D)” 480KHz
ZD1 102737 “DIODE,ZN,500MW,BM,12V,DO-35,TA” 12BM
AN101 109420 “CON ASS’Y,FL,10P,35022,CH0640,240MM” ASS’Y-10P
C201 120420 “CAP,CE,MONO,X7R,0.1UF,50V,K,2012,TA” 0.1U
C202 120420 “CAP,CE,MONO,X7R,0.1UF,50V,K,2012,TA” 0.1U
C203 120420 “CAP,CE,MONO,X7R,0.1UF,50V,K,2012,TA” 0.1U
C204 120420 “CAP,CE,MONO,X7R,0.1UF,50V,K,2012,TA” 0.1U
C205 120420 “CAP,CE,MONO,X7R,0.1UF,50V,K,2012,TA” 0.1U
C206 120420 “CAP,CE,MONO,X7R,0.1UF,50V,K,2012,TA” 0.1U
C207 120420 “CAP,CE,MONO,X7R,0.1UF,50V,K,2012,TA” 0.1U
C208 120420 “CAP,CE,MONO,X7R,0.1UF,50V,K,2012,TA” 0.1U
C209 120420 “CAP,CE,MONO,X7R,0.1UF,50V,K,2012,TA” 0.1U
C210 120420 “CAP,CE,MONO,X7R,0.1UF,50V,K,2012,TA” 0.1U
CH1 119236 “LED,SMD,GRN,CLR,1U,1608,TA” C191KGKT
CH10 119236 “LED,SMD,GRN,CLR,1U,1608,TA” C191KGKT
CH101 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH102 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH103 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH104 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH105 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH106 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH107 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH108 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH109 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH11 119236 “LED,SMD,GRN,CLR,1U,1608,TA” C191KGKT
CH110 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH111 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH112 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH113 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH114 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH115 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH116 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH117 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH118 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH119 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH12 119236 “LED,SMD,GRN,CLR,1U,1608,TA” C191KGKT
CH120 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH121 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH122 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH123 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH124 119231 “LED,SMD,R/G,CLR,2U,1615,TA” C195KGJRKT
CH13 119236 “LED,SMD,GRN,CLR,1U,1608,TA” C191KGKT
CH14 119236 “LED,SMD,GRN,CLR,1U,1608,TA” C191KGKT
CH15 119236 “LED,SMD,GRN,CLR,1U,1608,TA” C191KGKT
CH16 119236 “LED,SMD,GRN,CLR,1U,1608,TA” C191KGKT
CH17 119236 “LED,SMD,GRN,CLR,1U,1608,TA” C191KGKT
FRONT B’D
