AD226 Instruction for Use - US Page 20
Intensity
AC: -10 to 120 dB HL
BC: -10 to 80 dB
Available Intensity Steps is 1, 2 or 5dB
Extended range function: If not activated, the Air Conduction output will be
limited to 20 dB below maximum output.
Extended range only available when mains powered
Frequency
range
125Hz to 8kHz.
125Hz, 250Hz, 500 Hz, 750Hz, 1500Hz or 8kHz may freely be deselected
Internal storage
500 patients
Data Connections
(sockets) for connection
of accessories
1 x USB A for keyboard or printer
1 x USB B for PC connection (compatible with USB 1.1 and later)
External devices (USB)
Standard PC keyboard (for data entry)
Supported printers: Please contact local distributer for a list of approved PC
printers.
Display
4,3” (480x272) TFT color display.
Compatible software
(optional)
Diagnostic Suite - Noah, OtoAccess and XML compatible
Dimensions (LxWxH)
30x23x9cm, 12x9x4 inches.
Weight
1.3kg / 2.9lb
Power supply
5VDC-max 1.6A UE10 type only
Batteries
4x1.5V/1.2V Alkaline/NiMH Type AA,
Note:
When the instrument is battery operated the maximum stimuli output level is
reduced 20dB
Operation environment
Temperature: 15-35°C
Re. Humidity: 30-90% Non condensing
Ambient pressure: 98-104 kPa
Transport and storage
Transport temperature: -20-50°C
Storage temperature: 0-50°C
Re. Humidity: 10-95% Non condensing
Warm up time
Approx. 1 minute
Included Parts
DD45 Audiometric headset
B71 Bone conductor
APS3 Patient response switch
Power cable
Operation manual CD
Multilingual CE Instructions for Use
Optional Parts
Amplivox Audiocups, noise reducing headset
EARTone Audiometric insert phones
Carrying case
Diagnostic Suite software (including USB cable)
OtoAccess™ Database
IP30 Insert phones
DD45 Audiometric headset
P3100 (Pediatric)
