Interchange Brands Framing Nailers: Operator’s Manual
Parts List for NSR83-21 Lista De Partes Para NSR83-21 Liste Des Pièces Pour NSR83-21
ORDER NO. DESC.
CODE
KIT # ITEM
98648 NSR83K1 Kit #1 O-Ring/Gasket Kit for NSR83-21
98650 NSR83K2 Kit #2 Piston/Driver Assembly for NSR83-21
98652 NSR83K3 Kit #3 Head Cap Assembly for NSR83-21
98654 NSR83K4 Kit #4 Trigger Valve Assembly with Trigger for NSR83-21
98656 NSR83K5 Kit #5 Magazine Assembly for NSR83-21
98658 NSR83K6 Kit #6 Guide Body Assembly for NSR83-21
98659 NSR83K7 Kit #7 Safety Kit for NSR83-21
98660 NSR83K8 Kit #8 Feeder Kit for NSR83-21
98661 NSR83K9 Kit #9 Bumper Kit for NSR83-21
NOTICE: The parts listed in this
manual are for service assembly and
for reference. Changes to the tool
and drawing may be made without
notification.
Most parts or parts kits are available.
Contact your local dealer for more
information.
WARNING: When the tool needs
repairing or servicing, it is strongly
recommended that you contact your
local dealer. Do not disassemble the
tool yourself, which might waive your
right for product guarantee.
Parts Kits for NSR83-21
Kits de Partes Para NSR83-21 Liste Des Trousses De Pièces Pour NSR83-21
NO.
ORDER
NO.
DESCRIPTION NO.
ORDER
NO.
DESCRIPTION NO.
ORDER
NO.
DESCRIPTION
1 610260
BOLT M6X45
(Loctite 243)
33 640130 ROLL PIN 3X20 65 320370 VALVE PLATE
2 320300 EXHAUST COVER 34 410080 HANDLE GRIP 66 510340 O-RING 11.2X2
3 610220 BOLT M6X25 35 610280
BOLT M8X20 (Loctite
243)
67 310090
TRIGGER VALVE
BUSHING
4
110040 CYLINDER CAP
36
520100 END CAP SEAL
68
420310 TRIGGER STEM
5 520050
GASKET
37 110100
END CAP 69
510060
O-RING 3X1.8
6 520060 EXHAUST SEAL (A) 38 610090 BOLT M5X18 70 640440 STRAIGHT PIN B4X24
7 110050 EXHAUSTOR 39 640180 ROLL PIN 3X30 71 620930 ROLL SPRING
8 520070 EXHAUST SEAL (B) 40 320340 TRIGGER 72 210710 NAIL FEEDER
9 420260 EXHAUST VALVE 41 640210 ROLL PIN 3X45 73 322260 FIXED PIN
10 110060 PISTON BUMPER 42 420290 SAFETY GUARD 74 322270 YOKE
11 510660 O-RING 48.5X3.5 43 620090 SAFETY SPRING 75 610310 NUT M4 (Nylock)
12 310050 PISTON 44 322120 SAFETY (B) 76 630300 WASHER
13
322100
DRIVER BLADE
(Loctite 262)
45 322130 ADJUSTER 77 620940 SPRING
14 510880 O-RING 90.5X2 46 620920 SPRING 78 322290 SPRING SLEEVE
15 510800 O-RING 63X2.4 47 630240 STEEL BALL 79 322300 STOP LEVER
16 110070 CYLINDER COLLAR 48 322140 SAFETY (A) 80 610780 BOLT M4X30
17 510860 O-RING 79X2.45 49 324340 WASHER 81 610070 BOLT M5X12
18 310060 CYLINDER 50 610160
BOLT M6X10 (Loctire
243)
82 322310 MAGAZINE BRACKET
19 510830 O-RING 69X2.45 51 620160 PLUNGER SPRING 83 610320 NUT M5 (Nylock)
20 520080 CYLINDER SEAL 52 510100 O-RING 4X1.9 84 610330 NUT M6 (Nylock)
21 620140 CYLINDER SPRING 53 420300 PLUNGER (A) 85 322320 HANDLE ARM
22 320310 SPRING SEAT 54 510330 O-RING 11.2X1.5 86 322330 NAIL RAIL
23 110080 CYLINDER RING 55 310070 VALVE BUSHING 87 610520 BOLT M6X16
24 420270 BUMPER 56 510270 O-RING 9X1.9 88 310400 MAGAZINE
25 410070 EXHAUST SLEEVE 57 310080 VALVE SLEEVE 89 630070 SPRING WASHER
26 110090 BODY 58 510230 O-RING 7X1.5 90 630310 WASHER
27 510820 O-RING 64X2.4 59 510130 O-RING 4.6X1.5
28 520090 BODY SEAL 60 320350 WASHER P1 D322091 DRIVER UNIT
29 610200
BOLT M6X20
(Loctite 243)
61 620170 PLUNGER (B) SPRING P2 T310071 PLUGER VALVE
30 322250 GUARD COVER 62 320360 PLUNGER (B) P3 T310091 TRIGGER VALVE
31 210680 NOSE 63 410090 VALVE RUBBER WASHER
32 610300
BOLT M8X25
(Loctite 243)
64 410100 RUBBER BALL
