24
Interchange Brands Framing Nailers: Operator’s Manual
Parts List for NSC83-34 Lista De Partes Para NSC83-34 Liste Des Pièces Pour NSC83-34
ORDER
NO.
DESC. CODE KIT # ITEM
98636 NSC83K1 Kit #1 O-Ring/Gasket Kit for NSC83-28 & NSC83-34
98638 NSC83K2 Kit #2 Piston/Driver Assembly for NSC83-28 & NSC83-34
98640 NSC83K3 Kit #3 Head Cap Assembly for NSC83-28 & NSC83-34
98642 NSC83K4 Kit #4 Trigger Valve Assembly with Trigger for NSC83-28 & NSC83-34
98644 NSC83-34K5 Kit #5 Magazine Assembly for NSC83-34
98646 NSC83K6 Kit #6 Guide Body Assembly for NSC83-28 & NSC83-34
98647 NSC83K7 Kit #7 Safety Kit for NSC83-28 & NSC83-34
98649 NSC83K8 Kit #8 Feeder Kit for NSC83-28 & NSC83-34
98651 NSC83K9 Kit #9 Bumper Kit for NSC83-28 & NSC83-34
NOTICE: The parts listed
in this manual are for
service assembly and for
reference. Changes to the
tool and drawing may be
made without notification.
Most parts or parts kits
are available. Contact
your local dealer for more
information.
WARNING: When the
tool needs repairing or
servicing, it is strongly
recommended that you
contact your local dealer.
Do not disassemble
the tool yourself, which
might waive your right for
product guarantee.
Parts Kits for NSC83-34
Kits De Partes Para NSC83-34 Liste Des Trousses De Pièces Pour NSC83-34
NO.
ORDER
NO.
DESCRIPTION NO.
ORDER
NO.
DESCRIPTION NO.
ORDER
NO.
DESCRIPTION
1 610260
BOLT M6X45
(Loctite 243)
30 610300
BOLT M8X25 (Loctite
243)
59 410100 RUBBER BALL
2 320300 EXHAUST COVER 31 410110 NOSE RUBBER 60 320370 VALVE PLATE
3 610220 BOLT M6X25 32 640140 ROLL PIN 3X22 61 510340 O-RING 11.2X2
4 110040
CYLINDER CAP
33 620150
SAFETY SPRING 62
310090
TRIGGER VALVE
BUSHING
5 520050 GASKET 34 320330 SAFETY 63 420310 TRIGGER STEM
6 520060 EXHAUST SEAL (A) 35 610170
BOLT M6X12 (Loctite
243)
64 510060 O-RING 3X1.8
7 110050 EXHAUSTOR 36 420281 GUARD COVER 65 610330 NUT M6 (Nylock)
8 520070 EXHAUST SEAL (B) 37 410080 HANDLE GRIP 66 320320 HANDLE ARM
9 420260 EXHAUST VALVE 38 610280
BOLT M8X20 (Loctite
243)
67 320380 NAIL RAIL
10 110060 PISTON BUMPER 39 520100 END CAP SEAL 68 320390 MAGAZINE SLEEVE
11 510660 O-RING 48.5X3.5 40 110100 END CAP 69 420320 MAGAZINE COVER
12 310050 PISTON 41 610090 BOLT M5X18 70 640200 ROLL PIN 4X50
13 322090
DRIVER BLADE
(Loctite 262)
42 640180 ROLL PIN 3X30 71 210110 NAIL FEEDER PAWL
14 510880 O-RING 90.5X2 43 320340 TRIGGER 72 621020 FEED SPRING
15 510800 O-RING 63.X2.4 44 640210 ROLL PIN 3X45 73 420330 NAIL FEEDER
16 110070 CYLINDER COLLAR 45 420290 SAFETY GUARD 74 640270 STRAIGHT PIN
17 510860 O-RING 79X2.45 46 620160 PLUNGER SPRING 75 620180 ROLL SPRING
18 310060 CYLINDER 47 510100 O-RING 4X1.9 76 310100 MAGAZINE
19 510830 O-RING 69X2.45 48 420300 PLUNGER (A) 77 610380 BOLT M6X14
20 520080 CYLINDER SEAL 49 510330 O-RING 11.2X1.5 78 320400 NAIL STOPPER
21 620140 CYLINDER SPRING 50 310070 VALVE BUSHING 79 610520 BOLT M6X16
22 320310 SPRING SEAT 51 510270 O-RING 9X1.9 80 324340 WAHSER
23 110080 CYLINDER RING 52 310080 VALVE SLEEVE 81 630310 WAHSER
24 420270 BUMPER 53 510230 O-RING 7X1.5 82 630070 SPRING WASHER
25 410070 EXHAUST SLEEVE 54 510130 O-RING 4.6X1.5 83 610370 NUT M6
26 110090 BODY 55 320350 WAHSER P1 D322091 DRIVER UNIT
27 510820 O-RING 64X2.4 56 620170 PLUNGER (B) SPRING P2 T310071 PLUGER VALVE
28 520090 BODY SEAL 57 320360 PLUNGER (B) P3 T310091 TRIGGER VALVE
29 210100 NOSE 58 410090 VALVE RUBBER WASHER
To Next Page
