LCT-1 Ultimate
Specifications
• Insulation resistance { 5 GΩ at 10% accuracy (Min. >10 MΩ)}
• Input and output resistance: { 5 kΩ at 0.5 Ω resolution & ± 0.5 Ω accuracy}
• Sense resistance (for 6 wire L/C): up to 500 Ω at 0.1 Ω resolution
• Load cell output in percentage of full scale (input resistance > 175 Ω): ± 250%
at 0.01% resolution and 0.1 % accuracy
• Gain adjustment: {0.1 to 5 mv/V in steps of 0.01} of accuracy
• High resistance test: 10Vdc
• 16 bit A/D conversion
• Bridge test: 1.25Vdc
• Industrial 8-pin screw connector
• Bridge resistance and integrity
• Very user freindly, full test within seconds
• Size: 150mm x 80mm x 28mm; Weight: 250g
• Check 4 or 6-wire Load Cell connecting at all rated gain output
• Rugged ABS enclosure with rubberized over case for drop protection
• Continuous signal reading for checking linearity and repeatability
• Insulation resistance (points to moisture or chemical ingress)
• Physical distortion (zero balance)
• Alphanumeric display: 16 x 2 lines
