Air code display on unit panel
ñ If the drain pump malfunctions, the red , yellow and green
LEDs will blink with beeping sound.
Press reset button or any of the remote handset buttons, and the
beeping will stop.
ITEM RED LED YELLOW LED GREEN LED
High speed ON OFF OFF
Medium speed OFF ON OFF
Low speed OFF OFF ON
Pre-heat OFF BLINK OFF
Post-heat OFF OFF BLINK
Low temperature BLINK OFF OFF
protection of indoor coil
Over heat protection OFF BLINK BLINK
of indoor coil
Coil temperature ON BLINK BLINK
sensor damaged
Room temperature BLINK OFF BLINK
sensor damaged
Condensate pump damaged BLINK BLINK BLINK
Interklima Terminal Units
PCE -VS ñ Hydronic cassette
33
Troubleshooting
Error code display on wall pad definition table
The fan coil does not start up
Malfunction
No voltage
Cause Remedy
- Check for presence of voltage
- Check fuse on board
Mains switch in the "OFF position - Place in the "ON" position
Faulty room control - Check the room control
Faulty fan - Check fan motor
Air flow obstructed - Remove obstacles
Room control regulation - Check
Incorrect water temperature - Check
Air present - Vent
Insufficient output Filter clogged - Clean the filter
Loose screws - Tighten screws
Noise and vibrations Contact between metal parts - Check
CODE NO.
CODE NO.
CODE NO.
01
ROOM TEMPERATURE
SENSOR DAMAGED
06
CONDENSED WATER
OVER FLOW &
INDOOR COIL
TEMPERATURE
SENSOR DAMAGED
11
ROOM TEMPERATURE
SENSOR DAMAGED &
CONDENSED
WATER OVER FLOW &
AUTO RESTART FAILURE
02
CONDENSED WATER
OVER FLOW
07
ROOM TEMPERATURE
SENSOR DAMAGED &
CONDENSED WATER
OVER FLOW & INDOOR
COIL TEMPERATURE
SENSOR DAMAGED
12
INDOOR COIL
TEMPERATURE
SENSOR DAMAGED &
AUTO RESTART
FAILURE
03
ROOM TEMPERATURE SENSOR
DAMAGED & CONDENSED
WATER OVER FLOW
08
AUTO RESTART FAILURE
13
ROOM TEMPERATURE
SENSOR DAMAGED & INDOOR
COIL TEMPERATURE SENSOR
DAMAGED & AUTO RESTART
FAILURE
04
INDOOR COIL
TEMPERATURE
SENSOR DAMAGED
09
ROOM TEMPERATURE
SENSOR DAMAGED &
AUTO RESTART FAILURE
14
CONDENSED WATER OVER
FLOW & INDOOR COIL
TEMPERATURE SENSOR
DAMAGED & AUTO
RESTART FAILURE
05
ROOM TEMPERATURE SENSOR
DAMAGED & INDOOR COIL
TEMPERATURE SENSOR DAMAGED
10
CONDENSED WATER
OVER FLOW &
AUTO RESTART FAILURE
15
ROOM TEMPERATURE SENSOR
DAMAGED & CONDENSED WATER
OVER FLOW & INDOOR COIL
TEMPERATURE SENSOR DAMAGED
& AUTO RESTART FAILURE
