Interlogix ATS1201 8 User Manual

P/N 1052491 (ML) • REV D • ISS 01JUL19 5 / 40
Zone and output numbering
Refer to the appropriate ATS control panel installation guide.
Specifications
Mains power
Mains Input Voltage (J3 : AC)
230 VAC 10%, 50 Hz 10%
Current consumption at 230 V~
225 mA
Main board supply voltage
23 VAC typical
Power supply
Power supply voltage
13.8 VDC 5%
Power supply current
1.8 A max. at 13.8 VDC 5%
Auxiliary power output (J1)
13.8 VDC 5%, 475 mA max. [1]
Battery power output (J3: BAT)
13.8 VDC 5%, 1225 mA max.
(BS131) [2]
Battery type and max. capacity
Lead acid rechargeable 18 Ah
12 V nom. (BS131) [2]
Main board consumption
65 mA at 13.8 VDC 5%
[1] Maximum permanent current to power devices external to the
control equipment in the absence of alarm conditions.
[2] The specifications depend on the battery capacity. The above
table gives BS131 as an example
General features
End of line resistor (standard)
Refer to ATS control panel
installation guide
Standard on board output
Ext.siren (J7: S+/S−)
Electronic output
Rating: 1 A at 13.8 VDC
Dimensions metal housing LxWxH
360x260x82 mm
Colour
Beige
Operating temperature
0 to +50°C (certified +5 to 40°C)
Relative humidity
95% max. non condensing
IP protection grade
IP30
Fuses
F1
Auxiliary power & siren
F1 A, 20x5
F2
Battery
F3 A, 20x5
[1]
Mains fuse
F630 mA, 20x5
[1] Mains fuse is part of the mains terminal block.
WARNING: Before removing the mains fuse, mains power
must be disconnected.
Regulatory information
Manufacturer
PLACED ON THE MARKET BY:
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092, USA
AUTHORIZED EU REPRESENTATIVE:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings
and disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE
TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. UTC FIRE & SECURITY
CANNOT PROVIDE ANY ASSURANCE THAT
ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY “AUTHORIZED
DEALER” OR “AUTHORIZED RESELLER”, IS
PROPERLY TRAINED OR EXPERIENCED TO
CORRECTLY INSTALL FIRE AND SECURITY
RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code.
Certification
UTC Fire & Security hereby declares that this
device is in compliance with the applicable
requirements and provisions of the Directive
2014/30/EU and/or 2014/35/EU. For more
information see www.utcfireandsecurity.com or
www.interlogix.com.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
www.recyclethis.info
Contact information
www.utcfireandsecurity.com or www.interlogix.com
For customer support, see www.utcfssecurityproducts.eu
DA: Installations vejledning
Nettilslutning
Net-spænding 230 VAC med jord tilsluttes i terminalen for net-
tilslutning. Det anbefales at Net-tilslutningen sker som fast
installation via en nøglebetjent afbryder. Lokale retningslinjer
skal altid følges.
Benyt kabelbindere som trækaflastning for netkabel og
gummityller i kabelindgange.
ADVARSEL: Afbryd altid Net-spændingen, før kabinettet
åbnes.
Akkumulator udskiftning
Dette produkt indeholder en forseglet, genopladeligt, blygel
akkumulator. Da fjernelse af akkumulatorerne kan have
indflydelse på produktets konfiguration eller udløse en alarm,
bør udskiftningen af akkumulatorerne kun foretages af en
kvalificeret person.
For udskiftning af akkumulatorerne foretages følgende:
1. Kontroller at produktets indstilling, tillader åbning af
kabinettet uden at udløse en sabotage alarm.
