Advisor Advanced ATSx500A User Guide 13
1 2 3 4 5 6 7 8
█ [ ] √ x ? + +
Each area in the list has an indicator that describes its status. The following area
statuses are available.
Table 4: Area statuses and indicators for different keypads
Depending on the type of the list, you now have the following options.
Selecting areas in the list
• To select or deselect an area, enter the area number. Note that you can only
select areas that are currently shown on the display.
• To continue with selected, or with all areas if none selected, press Enter, or
Right, or 0.
• To cancel, press Clear.
Selecting areas in the symbolic line
All areas are selected by default.
• To select or unselect an area, enter the area number. Note that you can only
select areas that are currently shown on the display.
• To set or unset selected areas, press Enter or 0.
• To cancel, press Clear.
Area group list
If you are authorized to set or unset area groups, these will be displayed instead
of single areas.
Set or unset area groups the same way as described for areas above.
