Chapter 4: Programming
110 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
• Enter: Confirm the entry
• Clear: Exit without changes
How to program Yes/No options
• Up and Down arrow keys: Toggle between options
• Enter: Confirm the entry
How to edit text
Keys 1 to 9 have alphabetical characters printed above them. To enter a letter,
press the key the number of times relative to the position of the letter. Both upper
and lower case letters are available as well as numerical values and spaces. See
“Keypad layout” on page 112.
• 1 to 0: Enter a character
• Up: Delete a character
• Down: Backspace
• Left and Right: Move the cursor
• Function, and then Left: delete text backwards
• Function, and then Right: delete text onwards
• Enter: Confirm the entry
• Clear: Exit without changes
How to edit a list
• Up and Down: Toggle the value under cursor
• 0: Include or exclude all values in the list
• Left and Right: Move the cursor to a specific item
• Enter: Confirm the entry
• Clear: Exit without changes
If the number of allowed list elements is higher than 16, the list elements are
grouped, for example:
In this case, select a group first, and then edit the selected group as described
above.
