Chapter 5: Menu reference
242 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
• Enable: The alarm list option allows users to list active zones and faults as
well as alarms.
See “Keys” on page 54.
• Instant: Additionally to the alarm list option above, alarms are shown instantly.
Note: Alarms and faults are not shown if Armed display is active. See “8.3.1
Armed display” on page 241 for details.
8.3.4 Indicate faults
4 Indicate fault
>Always<
The option defines when faults are indicated on LEDs. The following options are
available:
• Always: Faults are always shown.
• On set: Faults are displayed only during system setting attempt.
8.3.5 View EE timer
The option defines if the entry and exit timers are displayed during setting and
unsetting the system.
8.4 Set options
1>RTS options
2 Inhibit incl
Options on the Set options menu define the set conditions.
8.4.1 RTS options
The RTS options menu defines conditions that can prevent setting. If a particular
condition below has this option set to Yes, its state affects the “Ready To Set”
state. The system does not allow for areas to set if any of the conditions are true.
For conditions related to areas, the condition is tested for those areas. For
example Zone 5 assigned to area 1 only affects the setting of area 1.
The following options are available.
• 1 Zone alarm: Active zone
• 2 Zone panic: Hold-up device active
• 3 Zone masking: Masking / fault state on input
• 4 Zone fault: Intrusion detector fault
• 5 Zone tamper: Tamper in zone
