Interlogix Simon XT Installation Guide

LED flashes Device status or error Description
6-blink
No Home ID present (lasts until the
module connects to Alarm.com and
is configured)
When the LTE module first connects
to Alarm.com it is configured with a
necessary unique network ID
Various module states (modes)
There are three module states, or modes, as described below:
Idle mode
AC power is OK and the module is not currently talking to Alarm.com.
L1 - Flashes errors, if any.
L2 - Communication with the panel.
L3 - Communication with radio unit. L4 - Signal level (zero to five bars).
L5 – Flashes errors, if any
PowerSave mode
The module just powered up, AC power is down, or AC power was recently restored and the battery is recharging. The
module is fully functional and will go into Connected Mode as soon as a signal needs to be sent. Press and hold [5] for
10 seconds to switch the module into Idle Mode and update the signal level reading. The system will go into Idle Mode
every two hours to check for any incoming messages.
L1 - Inactive.
L2 - Communication with the panel. L3 - Same flashing pattern as L2.
L4 - Inactive.
L5 - Inactive
Connected mode
The module is currently talking to Alarm.com. The module stays in Connected Mode for at least four minutes after
reporting an event to Alarm.com, unless [5] is pressed and held for 10 seconds, which will cause the module to go back
to Idle Mode.
L1 - Flashes errors, if any.
https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Panels/Interlogix_Simon_XT/Interlogix_Simon_XT_…
Updated: Tue, 31 Mar 2020 20:51:49 GMT
13

Interlogix Simon XT Specifications

Power

power requirements	6V nominal
standby current	30mA (10mA in PowerSave Mode)
peak current	1.7 A

Operating Environment

operating temperature	32 to 120°F (0 to 49°C)
storage temperature	-30 to 140°F (-34 to 60°C)
max. relative humidity	90% non-condensing

Dimensions

height	4 1/16 in.
width	1 7/8 in.
