CN50 and CN51 Single Dock (AD27)

Instructions

The CN50/CN51 single dock (Model AD27) powers your CN50

or CN51 computer and charges a spare battery (1015AB01 for

CN51, and AB24 or AB25 for CN50) separately. The single dock

also provides client and host USB connectivity.

What You Need

You also need these items (sold and ordered separately):

• Use only UL Listed power supply, which has been qualified by

Intermec with output rated at 12 VDC and 2.5 A with the

device.

• An appropriate AC power cord

• Ethernet or modem adapter and cables (optional)

Install and Use the Dock

1 Connect the power supply to the power connector on the

back of the dock.

Power connector

Note: Use the optional strain relief hardware to secure the

power supply cable to the dock.
