The wireless-2-channel insert switch ITL-2000 is ideal for switching on/
off 2 loads of up to 1000 watt each.
To be installed in the power supply to lamps or permanently wired
electrical appliances. For on-wall or recessed mounting!
Compatible with all intertechno wireless transmitters manufactured
in 1995 or later.
Mounting (only to be carried out by a qualified electrician):
1.) Turn off the main fuse.
2.) The connections must configured as shown in figure 1 and 2.
Encoding (Fig. 3)
Please also observe the operating instructions for your transmitter.
3.) Turn on the fuse again and have the desired transmitter ready to
hand.
The connections can now be checked by switching each channel on
and off by briefly pressing its own learning button (L) using a pointy
object (e.g. paper clip, ballpoint pen).
4.) By long-pressing of the learn button (L) so that the LED flashes, the
wireless receiver is ready to begin encoding the transmitter.
5.) Press the ON button on the transmitter.
The LED will flash 2x as confirmation.
The encoding is now complete.
Repeat points 4.) and 5.) for the second channel.
If no signal is transmitted within 10 seconds, the learning process is
automatically aborted.
16 different codes or transmitters can be taught in per channel.
Using several wireless receivers opens up many switching options such
as individual and group switching.
The encoding remains saved even after a power cut.
Erasing individual codes:
Proceed as described in points 4.) and 5.), however, press the OFF button
instead of the ON button.
GB
Operating instructions
›
ITL-2000
