Page 5
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts.
" * ": Optional.
When ordering parts, be sure to quote the model number and part numbers.
REF. NO.
DESCRIPTION QTY.
SPARE
PART NO.
SMALL AGP LARGE AGP
COMMON PARTS
1 AIR RELEASE VALVE/SEDIMENT RELEASE VALVE 2 10460
2 VALVE O-RING 2 10264
3 THREADED FILTER HOUSING COLLAR 1 10749
4 FILTER HOUSING COVER 1 10750
5 FILTER HOUSING O-RING 1 10325
6 FILTER CARTRIDGE (29000) 1
7 AIR RELEASE VALVE B (WITH O-RING) 1 10725
8 PUMP HOSE WITH NUTS 2 11009
9
WATER TRANSFER HOSE (WITH COLLAR AND 2 HOSE CLAMPS)
1 11583
10 SCREW 2 11519
11 FLOW SENSOR 1 11460
12 ELECTROLYTIC CELL NUT 2 11582
13 ELECTROLYTIC CELL (O-RING C INCLUDED) 1 11906
14 E.C.O. ELECTRODE 1 11900
15 L-SHAPE O-RING 1 11228
16 O-RING C 1 10712
17 ANGLE JOINT (O-RING D INCLUDED) 1 11584
18 O-RING A 1 11587
19*
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
2 10747
20* HOSE O-RING 2 10262
21* STEP WASHER 2 10745
22* STRAINER NUT 2 10256
23* FLAT STRAINER RUBBER WASHER 2 10255
24* THREADED STRAINER CONNECTOR 1 11235
25* ADJUSTABLE POOL INLET JET NOZZLE 1 12369
26* ADAPTOR B 2 10722
27* STRAINER CONNECTOR 1 11070
28* POOL INLET JET NOZZLE 1 12364
29* STRAINER GRID 1 11072
30 CELL COVER 1 11131
31 TITANIUM ELECTRODE 1 11899
32 TEST STRIPS 1 19635
33
TITANIUM ELECTRODE O-RING 2 11585
34
CONTROL STATION 1 11909
35
COLLAR NUT 1 11604
36*
AIR JET VALVE 1 12363
37*
INLET THREADED AIRCONNECTOR 1 12371
38*
INLET STRAINER CONNECTOR 1 12365
39*
POOL INLET AIR ADAPTOR 1 12368
40*
AIR JET VALVE CAP (NOT SHOWN) 1 12373
