(188IO) MODEL CS7220/7230 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/10/2012
188A
SAVE THESE INSTRUCTIONS
Page 21
English
STATIONARY MOUNTING
SALTWATER SYSTEM STATIONARY MOUNTING
Some countries, especially in the European community, require the product
to be secured to the ground or to a base in a permanent upright position.
Check with your local authorities to determine if there is a regulation in your
area regarding above-the-ground swimming pool filter pumps. If yes, then
the product can be mounted to a platform using the two holes located in the
base. See drawing below.
The product can be mounted on a cement base or onto a wooden platform
to prevent accidental tipping. Total assembly must exceed 18kg .
1. The mounting holes are 6.4 mm in diameter and spaced 90 mm apart.
2. Use two bolts and lock nuts with a maximum of 6.4 mm in diameter.
90 mm
