(188IO) MODEL CS7220/7230 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/10/2012
188A
SAVE THESE INSTRUCTIONS
Page 6
English
PARTS REFERENCE
When ordering parts, be sure to quote the model number and part numbers.
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
REF. NO.
DESCRIPTION QTY.
SPARE
PART
NO.
COMMON
PARTS
PARTS FOR
CONNECTION
TO FILTER
PUMPS WITH
1-1/4” (32MM)
HOSE SIZE
1
ADAPTOR A WITH THREADED COLLAR (OPTIONAL)
1 10849
2 O-RING A 1 10712
3 SCREW 2 11519
4 ELECTROLYTIC CELL (O-RING C INCLUDED) 1 11577
5 COPPER ELECTRODE 1 11579
6 TITANIUM ELECTRODE 1 11581
7 FLOW SENSOR 1 11460
8
CONNECTOR HOSE WITH THREADED FITTINGS
1 10720
9 THREADED ADAPTOR B (OPTIONAL) 1 10722
10
CELL COVER
2 11131
11 ELECTROLYTIC CELL NUT 1 11582
12 L-SHAPE O-RING 1 11228
13 COPPER ELECTRODE NUT 1 11580
14 CHLORINE TEST STRIPS 1 19635
15 COPPER TEST STRIPS 1 11254
16 TITANIUM ELECTRODE O-RING 1 11585
17 COPPER ELECTRODE O-RING 1 11586
18 CONTROL STATION 1 11591
