Intex Krystal Clear CS8220G User Manual

1
32
GS
SAVE THESE INSTRUCTIONS
Page 6
(132GS) MODEL CS8220G SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 11/17/2011
English
PPAARRTTSS RREEFFEERREENNCCEE
When ordering parts, be sure to quote the model number and part numbers.
REF. NO.
DESCRIPTION QTY.
SPARE
PART
NO.
COMMON
PARTS
PARTS FOR
CONNECTION
T
O FILTER
PUMPS WITH
1-1/4" (32MM)
HOSE SIZE
1 ADAPTOR A WITH THREADED COLLAR (OPTIONAL) 1 10849
2 O-RING A 3 10712
3 SCREW 4 10713
4
ELECTROLYTIC CELL (WITH TITANIUM
PLATES) (O-RING A INCLUDED)
1 11233
5 COPPER ELECTRODE 1 11234
6
FLOW SENSOR CONDUIT (O-RING B &
O-RING C INCLUDED)
1 11250
7 FLOW SENSOR 1 11460
8 CONNECTOR HOSE WITH THREADED FITTINGS 1 10720
9 THREADED ADAPTOR B (OPTIONAL) 1 10722
10
CELL COVER
2 11131
11 CHLORINE TEST STRIPS 1 19635
12 COPPER TEST STRIPS 1 11254
13 COPPER ELECTRODE NUT 1 11488
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.

Intex Krystal Clear CS8220G Specifications

General

Brand	Intex
Model	Krystal Clear CS8220G
Category	Swimming Pool Filter
Language	English
