When ordering parts, be sure to quote the model number and part numbers.
PARTS (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
REF.
NO.
DESCRIPTION QTY.
SPARE PART NO.
4 ADULTS 6 ADULTS
1 CONTROL BASE 1 13028 13028
2 SPA FILTER MOTOR 1 12778 12778
3 CONTROL PANEL 1 13023 13023
4 SIDE COVER HINGE BASE 2 12771 12771
5 AIR PRESSURE RELEASE VALVE CORE 1 12589D 12589D
6 CONTROL BASE SIDE COVER 2 12770 12770
7 SPA INFLATION HOSE 1 11830 11830
8 SPA CONTROL INLET/OUTLET O-RING 2 11788 11788
9 SIDE COVER HINGE FIXER 2 12772 12772
10 SPA DRAIN PLUG 1 13076 13076
11 SPA DRAIN VALVE ADAPTOR 1 13036 13036
12 FILTER CARTRIDGE HOUSING 1 11798 11798
13 FILTER CARTRIDGE 3 11692 11692
14 FILTER CARTRIDGE HOUSING LID 1 11797 11797
15 INLET PLUG 1 11739 11739
16 SPA TUB 1 12724 12746
17 SPA COVER 1 11951 12117
18
SPA COVER INFLATABLE BLADDER (PRE-INSTALLED IN SPA COVER)
1 11884 12114
19 GROUND CLOTH 1 11933 12110
20 ELECTROLYTIC CELL NUT WRENCH 1 11854 11854
21 TEST STRIPS 1 11855 11855
22 WRENCH 1 11742A 11742A
23 OUTLET PLUG 2 11782 11782
24 HOSE ADAPTOR 1 12773 12773
25 MALE BUCKLE 8 11994 11994
26 FEMALE BUCKLE 8 11993 11993
27 SPA CONTROL AIR INLET O-RING 1 11687 11687
28 ELECTROLYTIC CELL COVER SCREW 4 11712 11712
29 ELECTROLYTIC CELL COVER 1 11890 11890
30 ELECTROLYTIC CELL COVER O-RING 1 11897 11897
31 ELECTROLYTIC CELL NUT 1 11852 11852
32 ELECTROLYTIC CELL 1 11851 11851
33 ELECTROLYTIC CELL O-RING 1 11853 11853
34 DEFLATION OUTLET CAP 1 12775 12775
35 DEFLATION HOSE ADAPTOR 1 12774 12774
