(332IO) 48”, 52” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 04/26/2022
332
A
S AVE THESE INSTRUCTIONS
Page 5
PARTS REFERENCE
(
continued
)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
REF.
NO.
DESCRIPTION
QUANTITY
SPARE PART NO.
48" 52"
48" 52" #28076 #28077
1 U-SHAPED TOP RAIL 2 2 12512A 12512A
2
TOP PLATFORM 1 1 12182 12182
3 CLASP 2 2 12190 12190
4
SHORT FASTENER FOR U-SHAPED TOP RAIL
(WITH 1 EXTRA)
11 9 10810 10810
5
LONG FASTENER FOR TOP PLATFORM (WITH
1 EXTRA)
5 5 10227 10227
6
A SIDE - UPPER SIDE LEG (MARKED “A”) 1 1 12669AA 12643AA
7
A SIDE - UPPER SIDE LEG (MARKED “B”) 1 1 12669AB 12643AB
8
A SIDE - LOWER J- LEG (MARKED “A”) 1 1 12670AA 12644AA
9
A SIDE - LOWER J- LEG (MARKED “B”) 1 1 12670AB 12644AB
10
STEP 6 8 12629 12629
11
STEP ANCHOR SLEEVE 12 16 12630 12630
12 B SIDE - UPPER SIDE LEG (MARKED “A1”) 1 1 12653AA 12653AA
13 B SIDE - UPPER SIDE LEG (MARKED “B1”) 1 1 12653AB 12653AB
14 B SIDE - LOWER SIDE LEG (MARKED “A1”) 1 1 12651AA 12654AA
15 B SIDE - LOWER SIDE LEG (MARKED “B1”) 1 1 12651AB 12654AB
16 C SIDE - UPPER SIDE LEG (MARKED “C”) 2 2 12652A 12655A
17 C SIDE - LOWER U-SHAPED SIDE LEG (MARKED “C”) 1 1 12650A 12650A
18 SUPPORT BASE 2 2 11356 11356
IMPORTANT
It is very important to lay out the parts correctly and identify which parts connect
together before starting the assembly. Although some parts look alike, they are
not always interchangeable. Refer to the parts list.
This ladder is designed and manufactured for Intex pool wall height:
Item # Pool Wall Height Item # Pool Wall Height
28076 48” (122cm) 28077 52” (132cm)
To Next Page
