Intex SX3000 User Manual

342
GS
SAVE THESE INSTRUCTIONS
(342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/06/2022
English
Page 7
REF. NO. DESCRIPTION
SPARE
PART
NO.
QTY.
Individually
Pool set
1-1/2”
(38mm)
Pool set
1-1/4”
(32mm)
1 PRESSURE GAUGE 11224 1 1 1
2 6-WAY VALVE 11496 1 1 1
3 DRAIN OUTLET COVER 11131 1 1 1
4 CLAMP 11380 1 1 1
5 TANK O-RING 11379 1 1 1
6 SAND SHIELD 11382 1 1 1
7 CENTER PIPE HUB 11813 1 1 1
8 LATERAL 11384 12 12 12
9 DRAIN VALVE CAP 11456 1 1 1
10 DRAIN VALVE O-RING 11385 1 1 1
11 L-SHAPE O-RING 11228 4 4 4
12 HOSE WITH NUTS 11769 2 2 2
13 SAND FILTER INTERCONNECTING HOSE 11388 1 1 1
14 LEAF TRAP NUT 11479 1 1 1
15 LEAF TRAP O-RING 11232 1 1 1
16 BASKET 11260 1 1 1
17 FILTER HOUSING NUT 11261 1 1 1
18 L-SHAPE O-RING 11412 1 1 1
19
AIR RELEASE VALVE/SEDIMENT RELEASE VALVE 10460 2 2 2
20 VALVE O-RING 10264 2 2 2
21
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED) 10747 - 2 -
22 HOSE O-RING 10262 - 2 -
23 STEP WASHER 10745 - 2 -
24 STRAINER NUT 10256 1 2 -
25 FLAT STRAINER RUBBER WASHER 10255 1 2 -
26 THREADED STRAINER CONNECTOR 10744 - 1 -
27 ADJUSTABLE POOL INLET JET NOZZLE 12369 1 1 -
28 ADAPTOR B 10722 - - 2
29 STRAINER CONNECTOR 11070 - - 2
30 POOL INLET JET NOZZLE 13162 - - 1
31 STRAINER GRID 12197 - - 1
32 SCREW 11381 2 2 2
33 PUMP MOTOR & CONTROL
12708GS 111
34 PRE-FILTER ASSEMBLY 11371 1 1 1
35 LEAF TRAP COVER 11480 1 1 1
36 SAND FILTER PUMP MOTOR INLET O-RING 11457 2 2 2
37 SAND FILTER PUMP TANK 12713 1 1 1
38 SAND FILTER PUMP TANK BASE 12717 1 1 1
39 PRE-FILTER HOUSING 12099 1 1 1
40 STRAINER GRID 12198 - 1 -
41 AIR JET VALVE 12363 1 1 1
42 INLET THREADED AIR CONNECTOR 12372 1 1 -
43 POOL INLET AIR ADAPTOR 12368 - - 1
44 AIR JET VALVE CAP 12373 1 1 1
