SK2013-SON-002-TechMnl-SWC-002
Product range: SWC-ECM Hydronic High Wall with EC Motor
SWC-V~-ECM Hydronic High Wall 2-pipe with EC Motor
SWC-[Size]-V~-ECM
18
20
24
Unit Configuration
Configuration
2-pipe
Number Of Fan Blowers
Single
Power Supply
(V/Ph/Hz)
230/1/50
220/1/60
Operation Control
~S: Complete function onboard PCB with integrated group control functionality, incl. 1 pc
return air sensor and 2 pcs temperature sensors.
~W: Limited function onboard PCB with drain-pump, louver and zone control functionality,
incl. 1 pc coil temperature sensors.
Performance Data
Air
Total Air Flow
e
H
m
3
/hr
876
980
1240
M
740
760
1080
L
570
600
760
Cooling
Cooling Capacity
e
H
kW
4.38
5.19
6.25
M
3.84
4.23
5.61
L
3.12
3.50
4.23
Sensible Cooling Capacity
e
H
3.18
3.73
4.52
M
2.78
3.03
4.04
L
2.24
2.49
3.03
FCEER
e
Rating
213
180
126
Class
A
B
B
Heating
Heating Capacity
e
H
kW
5.25
6.14
7.44
M
4.58
4.97
6.65
L
3.68
4.09
4.97
Max. Electric Heater Capacity
1.6
FCCOP
e
Rating
255
212
153
Class
B
B
C
Soun
d
Sound PressureLevel ( Outlet )
dB(A)
46/40/34
41/35/30
48/45/35
Sound Power Level ( Outlet )
e
57/51/45
52/46/41
59/56/46
Electrical
Fan Motor Power
e
H
W
30
45
83
M
20
24
60
L
13
18
24
Fan Motor Apparent Power @ H
83
90
200
Fan Motor Running Current @ H
A
0.272
0.4
0.75
Hydraulic
Cooling Water Flow Rate
H
L/h
752
889
1072
M
658
727
961
L
536
601
727
Cooling Pressure Drop
e
H
kPa
19.4
19.8
27.2
M
15.5
14
22.6
L
10.8
10.1
14
Heating Water Flow Rate
@H/M/L
L/h
Same as "Cooling Water Flow Rate"
Heating Pressure Drop
e
H
kPa
16
16
25
M
13
12
19
L
8
8
13
Water Content
L
0.192
0.252
0.252
Construction
and Packing Data
Water
Connections
Type
Socket (Threaded Female)
In
mm [in]
12.70 [1/2]
Out
Condensate Drainage Connection
16 [0.63]
Dimensions
L
mm
876
1063
W
228
240
H
300
310
Net Weight
Kg
14
16
16
1."e" refers to technical information listed on the Eurovent website. Eurovent testing conditions:
a. Cooling mode (2-pipe):
b. Heating mode (2-pipe):
- Return air temperature: 27C DB/ 19C WB.
- Return air temperature: 20C.
- Inlet/ outlet water temperature: 7C/ 12C.
- Inlet water temperature: 50C.
- Water flow-rate: variable.
- Water flow-rate: same as 2-pipe cooling.
