Intrasonic Technology I600 - 1 Introduction; 2 Specifications; 3 1600 Assembly

Intrasonic Technology | 9525 Forest View Street | Dallas, Texas 75243|877‐435‐0670
pg.
4
1
Introduction
This user manual is designed to help the new users navigate and perform common tasks with the IST‐I600 Audio
system. Thank you for choosing the IST‐1600.
2 Spec
Power: 100‐240VAC 2.5A 50/60Hz
3.5mm input: 1Vp‐p20‐20KHz
RCA input (AUX IN): 1Vp‐p20‐20KHz
RCA output (AMP OUT): 1.6Vp‐pmax.20‐20KHz
RMS Output Power: 8x10W@8ohm max.
LCD: 4.3” TFT, resistor touch panel
USB connector output: DC5V 500mA
30 pin connector output: DC5V 500mA
3 I600 assembly
