Invacare 6291-A - Paddle Walker (6291) Folding

8
PADDLE WALKER (6291) -
A. Depress either release paddle and pivot the corresponding side
frame inward toward the front crossbrace. Refer to DETAIL
"C" in FIGURE 2.
B. Repeat the same procedure for the remaining side frame.
FIGURE 2 - FOLDING WALKERS
Palm Release
Button (“click”)
Side
Frames
DETAIL "A"
DETAIL "B"
SINGLE-RELEASE
WALKER (6281)
BLUE-RELEASE
WALKER
(6241)
DETAIL "C"
Side
Frames
PADDLE
WALKER (6291)
Dual
Release
Paddles
LOCKED
UNLOCKED
Release
Mechanism
Dual-Release
Mechanisms
Side
Frame
Front Crossbrace
