Setup
1.PlacethedrillingtemplateHonthetableandholdit
inplace.
2.Usingacentrepunch,markthetwodrillholesindicated
bythetemplate.
3.Drillthetwoholeswithadepthof12mmintothe
tableusingasuitable5mmdrillbit.
4.ScrewthetwocollaredscrewsF(includedinmounting
kit)intotheholesuntiltheymeetresistance.
5.Placethebatterychargeronthetablebyaligningholes
Iwiththeprotrudingscrews.
6.Slightlyturnthebatterychargerclockwisetolockitin
place.
InstallingToWall
•Centrepunch
•(Cordless)Screwdriver,6mmdrillbit,4mm
Phillipsscrewinsert
•Pocketrule(orsimilar)
Fig.3-3
1.Usingacentrepunch,markthetwodrillholesatthe
wallwhereyouwanttomountthecharger .
Thedistancebetweenthetwoholesmustbe120
mm.
2.Drillthetwoholesintothewallusingasuitable6mm
drillbit.
3.Placeawall-plugE(includedinmountingkit)intoeach
hole.
4.ScrewtwoscrewsD(includedinmountingkit)intothe
holeswhileleaving10mmofthescrewsprotruding.
5.Placethebatterychargertothewallbyaligningholes
Jwiththeprotrudingscrews.
1636951-C
11
