Invacare®OptiCharge
3Setup
3.1InstallingBatteryCharger
Thebatterychargercanbeplacedonitsrubberfeetona
horizontalsurfaceorbemountedtotheoorortothewall.
WARNING!
–Makesurethatnowires,pipesorotherutility
connectionswillbepiercedwhendrillinginthe
mountingsurface.
–Makesurethatthemountingsurfaceissuitable
fordrilling.
InstallingHolderForXLRPlug
•TX20Torxkey
Fig.3-1
1.MountholderBtothehousingusingscrewC.
InstallingToTable
•Centrepunch
•(Cordless)screwdriver,5mmdrillbit,5mm
Phillipsscrewinsert
•Drillingtemplate(Seeendofthisdocument)
Fig.3-2
IMPORTANT!
Thedrillingtemplateisonlyvalidwhenprintedin
theoriginallesizeat100%scale.
–Checkthedrillingtemplateforcorrect
dimensions.
–Ifnecessary,createyourowndrillingtemplate
withthegivendimensions.
