WARNING/CAUTION LABEL LOCATION - FWD MODELS (R2
JR
)
WARNING
Replacement con-
troller MUST be
SAME part number.
Motor
Assembly
Controller
(Back View)
CAUTION
Repositioning the motors WILL af-
fect the stability and/or perfor-
mance of the wheelchair. Refer to
PERCENTAGE OF WEIGHT DISTRIBU-
TION in the Owner's Manual BEFORE
repositioning motors. 1080267
Side Frame
WARNING
Pinch Point
Side Frame
Battery
Tray
GENERAL GUIDELINESPROCEDURE 1
G
E
N
E
R
A
L
G
U
I
D
E
L
I
N
E
S
Wiring Harness
for Battery
Box Lid
