11
BATTERY WARNING LABEL LOCATION
WARNING
This POSITIVE (+) RED Battery Cable MUST
connect to the POSITIVE (+) Battery
Terminal(s)/Post(s), otherwise serious
damage will occur to the electrical sys-
tem. Refer to the Owner’s Manual. DO
NOT remove this label. 1095558
WARNING
This NEGATIVE (+) BLACK Battery Cable
MUST connect to the NEGATIVE (+) Bat-
tery Terminal(s)/Post(s), otherwise serious
damage will occur to the electrical sys-
tem. Refer to the Owner’s Manual. DO
NOT remove this label. 1095559
WARNING
DO NOT allow battery cable(s) to contact
the opposite battery terminal(s)/post(s). Re-
place cable(s) immediately if cable(s) insu-
lation becomes damaged. Failure to observe
these warnings may result in an electrical
short with serious personal injury resulting.
DO NOT remove this label. 1095561
NOTE: Only U1 battery box top is show for clarity.
Warning Labels are located on the group 22 battery
box top in the same manner.
NOTE: These warning labels are found on models built
after 3/1/00. For warning label locations on chairs built
before 3/1/00, refer to specific drive system for the
wheelchair.
GENERAL GUIDELINES PROCEDURE 1
G
E
N
E
R
A
L
G
U
I
D
E
L
I
N
E
S
