INVENTOR ATM08S User Manual

87
Matrix Mono
Part 3 - Installaon and Field Sengs
Matrix Mono
86
Inventor Matrix Mono Engineering Data Book
7.10 OTHER HEATING SOURCE Menu
7.10.1 OTHER HEATING SOURCE menu overview
MENU > FOR SERVICEMAN > OTHER HEATING SOURCE
Figure 3-7.26: OTHER HEATING SOURCE menu
In OTHER HEATING SOURCE the following parameters should be set. Backup electric heater is optional.
dT1_IBH_ON sets the temperature difference between the heat pump’s leaving water set temperature (T1S) and the heat
pump’s leaving water temperature (T1) above which the backup electric heater heating element(s) are on. When T1S - T1 ≥
dT1_IBH_ON the backup electric heater is on (on models where the backup electric heater has a simple on/off control
function).
t_IBH_DELAY sets the delay between the compressor starting and the backup electric heater being turned on.
T4_IBH_ON sets the ambient temperature below which the
backup electric heater is used. If the ambient temperature is
above T4_IBH_ON, the backup electric heater is not used. The
relationship between operation of the backup heater and the
ambient is shown in Figure 3-7.22.
dT1_ASH_ON sets the temperature difference between the heat pump’s leaving water set temperature (T1S) and the heat
pump’s leaving water temperature (T1) above which the additional heating source is on. When T1S - T1 ≥ dT1_AHS_ON the
additional heating source is on.
t_ASH_DELAY sets the delay between the compressor starting and the additional heating source being turned on.
T4_AHS_ON sets the ambient temperature below which the additional heating source is used. If the ambient temperature
is above T4_ASH_ON, the additional heating source is not used. The relationship between operation of the additional
heating source and the ambient is shown in the picture below.
IBH LOCATE means IBH is installed for pipe heating.
P_IBH1, P_IBH2 set heating capacity of IBH and P_TBH sets heating capacity of TBH, which are used for energy
consumption statistics.
30MIN
-5°C
5°C
30MIN
5°C
7 OTHER HEATING SOURCE
7.1 dT1_IBH_ON
7.2 t_IBH_DELAY
7.3 T4_IBH_ON
7.4 dT1_AHS_ON
7.5 t_AHS_DELAY
ADJUST
1/2
Figure 3-7.27: T4_IBH_ON
Abreviations:
T4: Outdoor ambient temperature
IBH: Backup electric heater
Figure 3-7.28: T4_AHS_ON
Abreviations:
AHS:
Additional heating source
T4: Outdoor ambient temperature
Matrix Mono
87
Part 3 - Installation and Field Settings
7.11 HOLIDAY AWAY SETTING Menu
MENU > FOR SERVICEMAN > HOLIDAY AWAY SETTING
The HOLIDAY AWAY SETTING menu settings are used to set the outlet water
temperature to prevent water pipes freezing when away from home in cold
weather seasons. In HOLIDAY AWAY SETTING the following parameters should
be set.
T1S_H.A._H sets the heat pump’s leaving water set temperature for space
heating mode when in holiday away mode.
T5S_H.M_DHW sets the heat pump’s leaving water set temperature for DHW mode when in holiday away mode.
7.12 SERVICE CALL Menu
MENU > FOR SERVICEMAN > SERVICE CALL
In SERVICE CALL the following parameters can be set.
PHONE NO. and MOBILE NO. can be used to set after-sales service contact numbers. If
set, these numbers are displayed to users in MENU > FOR SERVICEMAN > SERVICE
CALL
Use ▼ ▲ to adjust the numerical values. The maximum length of the phone numbers
is 14 digits.
The black rectangle found between 0 and 9 when scrolling up and down using ▼ ▲ is converted to a blank space when
the phone numbers are displayed to users in MENU > FOR SERVICEMAN > SERVICE CALL
and can be used for phone
numbers less than 14 digits in length.
7.13 RESTORE FACTORY SETTINGS
MENU > FOR SERVICEMAN > RESTORE FACTORY SETTINGS
RESTORE FACTORY SETTINGS is used to restore all the parameters set in the user interface to their factory defaults.
On selecting YES
, the process of restoring all settings to their factory defaults begins and progress is displayed as a
percentage.
Figure 3-7.31: RESTORE FACTORY SETTINGS screens
10 RESTORE FACTORY SETTINGS
All the settings will come back to
factory default.
Do you want to restore factory
settings?
OK CONFIRM
NO YES
Please wait…
5%
10 RESTORE FACTORY SETTINGS
Figure 3-7.29: HOLIDAY AWAY SETTING menu
Figure 3-7.30: SERVICE CALL menu
20°C
20°C
8 HOLIDAY AWAY SETTING
8.1 T1S_H.A._H
8.2 T5S_H.A._DHW
ADJUST
ADJUSTOK CONFIRM
9 SERVICE CALL SETTING
PHONE NO. 0000000000000
MOBILE NO. 0000000000000
