590
560
41
490
520
min. 40**
min. 25*
* 60mm when using a back of wood.
** 150mm when using a sidewall of
wood.
INSTALLATION DIMENSIONS
In the drawing below, all the dimenions are displayed in mm.
SPACE AROUND THE HOB
Sufficient clearance around the hob is essential for a safe use of the hob. Check that there is sufficient clearance.
