removing the top panel
10
To install the freezer beneath a counter top for example, you
can easily remove the top panel.
Note: unplug the appliance.
• Remove the screws at the back, holding the top panel to
the appliance.
• Lift the top panel at the backside and remove it.
• Remove the screws on both the frame and the metal
hinge.
• Remove the hinge and the frame. Hold the door tight to
the appliance.
• Reassemble the metal hinge using the three screws.
• Leave the appliance to stand for at least 3 hours before
you insert the plug into the socket.
20 • English
