Thank you for purchasing our Power Inverter.lt is a compact and highly portable power
inverter Which has an excellent track record in the field of high frequency inverter. From the
12V/24V/48V DC outlet in your vehicle or boat, or directly from a dedicated 12V/24V/48V DC
battery,this inverter can efficiently and reliably power a wide variety of house hold AC products,
such as TV, Computers,Air-conditioner etc. Please read this guide before installing or using the
inverter and save it for future reference.
Due to our continuous work to upgrade and improve our products, we may change or revise
the contents of this manual instructions or any part of it without giving any further notice.
Contents
Contents
1、Models and Denotations
2、Safety First
3、Products Features and Applications
4、Pure Sine Wave and Modified Sine Wave Inverter
5、Guidelines
5.1 Installation Conditions
5.2 Working Principle
5.3 Connection Method
5.4 Battery｀s C harge
5.5 Inverte｀r s W orking S tatus
6、The Sketch of Inverter
7、Inverter to Battery Connections Details
8、Trouble Shooting
9、Specifications
……………………………………………………………
…………………………………………………
…………………………………
……………………………………………………………………………
…………………………………………………………
………………………………………………………………
………………………………………………………………
……………………………………………………
……………………………………………………………
……………………………………………
…………………………………………………………………
……………………………………………………………………
1
………………………………………………………………………
2-3
4
5
6
6
7
……………………………………………………………
7-8
8
9-10
11-15
16
17-21
22-24
- 1-
Models and Denotations
Type:TypeA,TypeB,TypeC,TypeD,TypeE,TypeF,TypeG;
75W,100W,150W,200W,300W,500W,600W,800W,1000W,1200W,1500W,
2000W,2500W,3000W,4000W,5000W,6000W,8000W,10000W,
1210,1215,1220,1230,1250,2410,2415,2420;
1205,2405,1210,2410,1215,2415,1220,2420,1230,2430,1250,2450,
1260,2460,1280,2480,12100,24100;
P:Pure sine wave inverter M:Modified sine wave inverter
PU:Pure sine wave inverter with charger
MU:Modified sine wave inverter with charger
CH:Battery charger SY:Movable solar power system;
Company code;
Safety First
WARNING! Shock hazard. Keep away from children.
1-1. The inverter generates the same potentially lethal AC power as a normal household
wall outlet. Treat it as if you are using any other AC outlet.
1-2. Do not insert foreign objects into the inverter′s A C o utlet, f an o r vent openings.
1-3. Do not expose the inverter to water, rain, snow or spray.
1-4. Do not under any circumstance, connect the inverter to AC power.
WARNING! Heated surface.
1-5. The inverter housing may become uncomfortably warm, reaching 140F(60℃)
under extended high power opeartion. Ensure at least 2 inches (5cm) of air space is
maintained on all sides of the inverter.During operation, keep away from materials that
may be affected by high temperature.
WARNING! Explosion hazard.
1-6. Do not use the inverter in the presence of flammable fumes or gases, such as in
the bilge of a gasoline powered boat,or near a propane tanks. Do not use the inverter in
