Thicknesser
Model DGI-63D
Replacement Parts
FIG. CODE QTY. NAME FIG.
CODE QTY. NAME
71…. 81DS-K120-0 88… Hammer
106… 84DS-KK54-0 02… Table guide
72…. 8NAR-KK48-0 95… Washer 107… 10-03-0083-0 01… Panel
73…. 8NVL-K211-0 01… Plain rod 108… 11-27-0002-0 01… Red switch off button C2-111
74…. 07-00-0036-0 01… 8NMO-KK71-0 109… 11-27-0001-0 01… Green switch on button B2-111
75…. 89DS-K105-0 01… Chip chute (optional) 110… 06-09-0019-0 05… Hex nut M6x0,8
76…. 06-04-0136-0 07… Hex head cap screw M6x1x12 111… 06-03-0097-0 01… Allen screw with head M10x1,5x30
77…. 06-13-0002-0 07… Washer plain Ø1/4” 112… 89DS-KK54-0 01… Electric box cover
78…. 89DS-KK16-0 01… Chip outlet plate 111… 06-09-0021-0 02… Hex nut
79…. 06-05-0039-0 07… Round head screw M6x1x10
80…. 89DS-K101-0 01… Chip outlet 115… 06-13-0033-0 02… Lock washer Ø8,4x2
81…. 06-03-0063-0 04… Allen screw with head M10x1,5x3
5 116… 89DS-KK55-0 01… Electric box support
82…. 89DS-KK60-0 01… Upper cover 117… 06-04-0096-0 08… Hex head cap screw M6x1x25
83…. 06-04-0115-0 01… Hex head cap screw M8x1,25x16 118… 82DX-K172-0 04… Hinge
84…. 8NAR-KK62-0 01… Washer 119… 82DX-K173-0 04… Hinge
85…. 88DS-K182-0 01… Handwheel 120… 06-03-0066-0
02… Allen screw with head M8x1,25x20
86…. 06-03-0033-0 01… Allen screw with head M8x1,25x70 121… 27-01-0033-0 01… Knob
87…. 89DS-KKK9-0 01… Right hand side cover 122… 06-04-0084-0 01… Hex head cap screw M10x1,5x70
88…. 06-13-0034-0 02… Washer lock Ø13x2,5mm
123… 06-13-0026-0 02… Washer plain Ø10mm
89…. 06-03-0103-0 02… Allen screw with head M12x1,75x45 124… 89DS-KKK2-0 01… Laft hand lower cover
90…. 06-13-
0031-0 06… Washer plain Ø8mm 125… 06-09-0020-0 02… Hex nut M8x1,25
91…. 06-04-0083-0 06… Hex head cap screw M8x1,25x30 126… 84DS-K150-0 01… Brake
92…. 06-04-0119-0 01… Hex head cap screw M8x1,25x25 127… 89DS-KKK8-0 01… Left hand cover
93…. 8NAR-KK81-0 02… Washer 128… 8NAR-K113-0 01… Washer
94…. 87DS-KK84-0 01… Chain stretcher 129… 06-04-0121-0 01… Hex head cap screw M10x1,5x30
95…. 87DS-K137-0 01… Chain stretcher gear 130… 26-01-0008-0 02… Pin extension Ø5x40mm
96…. 8NAR-KK96-0 01… Washer 131… 84DS-K112
-0 01… Cutter adjusting device
97…. 89DS-KKK5-0 01… Right hand lower cover 132… 88DS-K243-0 01… Gauge block (optional)
98…. 06-03-0072-0 04… Allen screw with head M6x1x30 133… 84DS-KK10-0 01… Table guide (right side)
99…. 88DS-K125-0 03… Panel spacer 134… 89DS-KK98-0 01… Table guide (left side)
100… 06-05-0051-0 03… Round head screw M6x1x30
135… 06-05-0039-0 04… Round head screw M6x1x10
101… 10-03-0013-0 01… Right hand panel 89DS-K118-0 136… 89DS-KK74-0 01… Skirt support (right hand)
102… 89DS-KKK1-0 01… Base 137… 06-02-0043-0 04… Allen screw without head M6x1x16
103… 10-04-0043-0 01… Emblem 138… 06-13-0031-0 04… Pain washer Ø8mm
104… 06-17-0002-0 02… Rivet pop EAD-440-S 139… 06-04-0119-0 12… Hex head cap screw M8x1,25x25
105… 26-03-0011-0 04… Pin extension Ø8x24mm 140… 06-04-0106-0 04… Hex head cap screw M8x1,25x40
27
