Thicknesser
Model DGI-63D
Replacement Parts
FIG. CODE QTY. NAME FIG.
CODE QTY. NAME
01.… 06-04-0100-0 01… Hex head cap screw M12x1,75x35
36… 88DS-K173-0 01… Right hand bearing
02.… 84DS-K100-0 01… Cutter head washer 37… 8NCV-K311-0 01… Key
03.… 84DS-KK20-0 01… Cutter head pulley 38… 88DS-K143-0 01… Stop bumper
04.… 06-18-0026-0 02… Spring ring 39… 89DS-KK11-0 01… Right hand side
05.… 03-00-0077-0 01… Bearing 6208-2RS 40… 07-00-0035-0 03… Spring 8NMO-KK70-0
06.… 84DS-K208-0 01… Left hand bearing 41… 84DS-KK80-0 03… Spring adjustment nut
07.… 84DS-K209-0 01… O´ring 42… 07-01-0031-0 02… Spring 84DS-KK89-0
08.… 06-03-0063-0 02… Allen screw with head M10x1,5x35 43… 84DS-K177-0 02… Pressure bar screw
09.… 06-13-0023-0 02… Lock washer Ø10mm 44… 06-02-0088-0 04… Allen screw without head M10x1,5x10
10.... 26-03-0003-0 02... Pin elastic Ø8x36mm
45… 84DS-KK56-0 01… W
asher
11.… 06-13-
0034-0 03… Lock washer Ø13x2,5 46… 06-06-0034-0 01… Flat head screw M8x1,25x25
12.… 06-03-0099-0 03… Allen screw with head M12x1,75x35 47… 8NCO-KK25-0 01… Chain
13.… 87DS-K159-0 03… Spring adjustment nut 48… 16-23-0005-0 01… ISO-083 Chain junction
14.… 06-02-0060-0 01… Allen screw without head
M8x1,25x16 49… 89DS-KK51-0 01… Gear
15.… 06-02-0042-0 02… Allen screw without head M6x1x12 50… 88DS-K165-0
01… 2
nd
. Roller gear
16.… 89DS-KK10-0 01… Left hand side 51… 8NCO-KK26-0 01… Chain
17.… 06-03-0065-0 04… Allen screw with head M8x1,25x2
5 52… 16-23-0002-0 01… ASA-40 Chain junction
18… 84DS-K211
-0 01… Left hand pressure bar support 53… 88DS-K164-0 01… 1
st
. Roller gear
19.… 84DS-K180-0 02… Pressure bar pin 54… 06-18-0014-0 01… E-40 Spring ring
20.… 84DS-K130-0 01… Pressure bar blade 55… 84DS-K207-0 01… Right hand bearing
21.… 84DS-K210-0 01… Right hand pressure bar support 56… 82DG-K010-0 01… 1
st
. Feed roller
22.… 84DS-KK35-0 01… Cutterhead 57… 84DS-K052-0 01… Feed roller bearing
23.… 8NCV-K312-0 01… Key 58… 89DS-K127-0 01… Upper cover gasket
24.… 05-00-0004-0 03… Cutter 8NFC-KKK1-0 59… 88DS-K184-0 12… Chipbreaker adjustment screw
25.… 8NPF-KK20-0 21… Cutter screw 60… 07-00-0037-0 12… 8NMO-KK72-0 Spring
26.… 8NCV-K501-0 03… Key 61… 06-03-0068-0 02… Allen screw with head M10x1,5x50
27.… 07-00-0030-0 08… Spring 8NMO-KK55-0 62… 89DS-KK13-0 01… Spring bed
28.… 88DS-K174-0 01… Left hand bearing 63… 89DS-KK25-0 02… Chipbreaker stop bushing
29.… 8NCV-K242-0 01… Key 64… 89DS-KK24-0 01… Chipbreaker shaft
30.… 89DS-KK15-0 01… Feed roller 2
nd
. 65… 89DS-KK12-0 11… Chipbreaker
31.… 8NCV-K331-0 01… Key 66… 89DS-K131-0 01… Rod support
32.… 06-03-0078-0 02… Allen screw with head M6x1x12 67… 89DS-K130-0 01… Tie rod
33.… 88DS-K142-0 01… Outfeed roller stop 68… 89DS-K129-0 01… Chipbreaker
34.… 06-09-0020-0 01… Hex nut M8x1,25 69… 84DS-KK33-0 02… Back off bushing
35.… 06-02-0080-0 01… Allen screw without head M8x1,25x30 70… 8NVL-K272-0 01…
Plain rod
26
